COB P1.25、P1.5mm High-density And High Refresh Rate Indoor Installation LED Video Wall
Price:
Negotiable
MOQ:
Min. order: 20
Delivery Time:
15-22Days
Brand:
GCL
Product Description
P1.25,P1.5mm High-density And High Refresh Rate Indoor Installation LED Video Wall
Waterproof P1.25 LED Screen for Mall Advertising and Professional Applications
Ultra HD 2K/4K Display
27-inch screen with 16:9 golden ratio display, delivering ultra-clear 2K/4K image stitching. Features wide viewing angles (170° horizontal and vertical) for clear, lifelike images from any perspective.
All-Front Maintenance Design
Modules, power supplies, and accessories can be removed from the front for convenient maintenance. Modular magnetic design enables quick and easy service access.
Ultra-Thin Construction
Die-cast aluminum casing provides lightweight construction as thin as 32mm. No steel structure required, allowing easy wall-mounted installation in various settings.
Wireless Connectivity
Module and casing feature wireless interconnection for simplified installation, reducing wiring and labor costs. Dual power and signal backup systems provide protection against system malfunctions during power outages.
Enhanced Color Performance
Wide color gamut technology delivers richer color gradients and more authentic colors, significantly enhancing visual impact.
Flexible Installation Options
No steel structure required for wall installation, providing versatile mounting solutions.
Application Scenarios
- Business Display
- Conference Display
- Professional Display
GTV Series Technical Specifications
| Parameter | P0.9 | P1.2 | P1.5 |
|---|---|---|---|
| Pitch | 0.9375mm | 1.25mm | 1.5625mm |
| Pixel Density | 1,137,777/m² | 640,000/m² | 409,600/m² |
| LED Type | Flip Chip COB | ||
| Brightness | 600 nits | ||
| Scan Method | 1/40 | 1/40 | 1/48 |
| Panel Size | 600×337.5×29.2mm | ||
| Module Size | 150×168.5mm | ||
| Panel Material | Die-casting Aluminum | ||
| Panel Weight | 4.2kg | ||
| Protection Level | IP34 | ||
| Maintenance | Full Front Service | ||
| Max Power Consumption | 275W/㎡ | 245W/㎡ | 205W/㎡ |
| Average Power Consumption | 90W/㎡ | 80W/㎡ | 70W/㎡ |
| Refresh Rate | ≥3840Hz | ||
| Grey Scale | 13-16bit | ||
| Viewing Angle | H170°, V170° | ||
| Voltage | AC100~240V (50-60Hz) | ||
| Working Temperature | -20℃ to 60℃ | ||
| Working Humidity | 10%-90% RH | ||
| Color Temperature | 3000-9500K | ||
| Certifications | CE/ROHS/EMC/TUV/UL/CCC/FCC/ISO | ||
