Vertical Energy Saving Automatic Seam Welding Machine With High Technology
Price:
Negotiable
MOQ:
Negotiable
Delivery Time:
Negotiable
Product Description
For the tank welding machine, we has been sold more than 20 countries in more than 1000 projects sites.We have confidence for the machine quality and after sale service. We can provide single side, double side crude oil, LNG tank, fuel tank, water tank horizontal seam, vertical seam and bottom plate/corner welding machine.In Middle East, we have sold to UAE, Saudi Arabia, Oman, Bahrain, Kuwait. In Africa, we have sold machine to Cameron, Sudan, Egypt, Senegal, Nigeria, Zambia, Ethiopia, Senegal, etc. We have sold to vietnam, Indonesia ,Malysia , Philippines ,Singapore,Mexco,Mogulia, Russia,etc
Reference Specification
| Welding Process | Electrogas welding |
| Model | WEGW-I |
| Plate Thickness | 8 - 45mm |
| Plate Material | Carbon steel |
| Groove | Single V groove Double V groove |
| Seam Position | Vertical Weld /3 G welding |
| Min Tank Diameter | Φ6.0m |
| Plate Width | 1.6 - 3.0m (Can be customized ) |
| Power Input | 380V/3PH/50HZ (Can be customized ) |
| Erection Method | Bottom To Top and bottom to top |
| Dimension(L x W x H) | 4000mm x 1900mm x 1100mm |
| Gross Weight | 1200kg |
1, Support you to win the project during bidding phase. We can provide your more suitable configurations to help you shorten the constrcution time.
2, We can provide all technical documents and advices to support you for construction procedure clearifications
3, We can support you to calculate the roughly construction time based one welding efficiency, the calculation of manpower needed, welding consumbles quantity
4, We can provide your suitable welding consumbles with much more competetive price from our long time business partner if you need.
5, We can provide site people training service, and operation service or manpower service or as a subcontractor.
