30kW Water-Cooled High-Torque Motor Module with IP67 Protection for Hydraulic Pump Applications
The High-Torque Motor Module is a powerful permanent magnet synchronous motor (PMSM) engineered for demanding applications requiring high starting torque and continuous heavy‑duty operation. With 30kW rated power and 197 N·m torque at 1450rpm, it is ideally suited for driving hydraulic pumps, compressors, and other auxiliary systems on sanitation vehicles, construction equipment, and industrial machinery.
Designed for continuous duty (S1 operation), the motor features water cooling for superior thermal management during extended use. The IP67 ingress protection ensures complete dust‑tight and waterproof sealing, making it reliable in harsh outdoor environments. Class H insulation guarantees long‑term durability even under high‑temperature conditions.
- 30kW PMSM Technology – High efficiency, precise torque control, low maintenance
- High Torque Output – 197 N·m at 1450rpm for demanding hydraulic applications
- Water Cooling – Excellent thermal management for continuous duty
- IP67 Protection – Dust‑tight and waterproof for all‑weather operation
- 540V DC Compatibility – Optimized for electric and hybrid vehicle platforms
- S1 Continuous Duty – Designed for extended operating hours without interruption
- Class H Insulation – High‑temperature resistance for long‑term reliability
This motor module is available for OEM/ODM customization, allowing voltage, interface, and performance adjustments to meet your specific system requirements.
