Used Doosan DH225LC-7 Excavator Second Hand Doosan 225 300 Hydraulic Excavator with 1

Name:ShangHai Long shou Machinery Co,Ltd

Address: No 1688 South Lian Hua Road, MinHang district.ShangHai, P. R. China

Contact :Olivia

Whats app/Mobile phone:+8618701954897

We chat number:18701954897

specifications

Power Traditional Power

Manufacturer joint venture/import

Bucket Backhoe

Tonnage (ton) 22

Working weight of the whole machine (kg) 21500

Bucket capacity (m ³) 0.5-1.28

Boom length (mm) 5700

Stick length (mm) 2900

performance

Rotation speed (rpm) 12.4

Walking speed (km/h) 3.1-4.5

Bucket excavation force (kN) 136.2/144.1

Dipper arm excavation force (kN) 97/102.9

dynamic system

Engine model: Doosan DB58TIS

Rated power (kW/rpm) 110/1950

Displacement (L) 6.3

Cooling method: air cooling

hydraulic system

Main pump type variable axial piston pump

Maximum flow rate of main pump (l/min) 2 × 215

Main body size

Total length of transportation (mm) 9510

Total transportation width (mm) 2990

Total transportation height (mm) 3030

Full height of cab (mm) 3000

Track grounding length (mm) 3645

Total length of track (mm) 4440

Track shoe width (mm) 600

Total width of track (mm) 2990

Track gauge (mm) 2390

Minimum ground clearance (mm) 480

Ground clearance of counterweight (mm) 1105

Rear end turning radius (mm) 2750

Scope of work

Maximum excavation radius (mm) 9910

Maximum excavation radius of the parking surface (mm) 9735

Maximum excavation depth (mm) 6630

Maximum excavation height (mm) 9660

Maximum unloading height (mm) 6810

Maximum vertical excavation depth (mm) 6045

Maximum effective excavation depth (mm) 6445
