Ahu Chilled Watee Ahu Air Handling Unit Parts Industrial Floor Standing Air Conditioner 15 Kwt
Price:
consult customer service.
MOQ:
1
Delivery Time:
35days
Brand:
Jetex
Product Description
AHU Chilled Water Air Handling Unit Parts Industrial Floor Standing Air Conditioner 15 kW
Customizing an Air Handling Unit (AHU) involves precisely matching the unit to your project's specific application, environment, standards, and client requirements. This framework provides a clear, practical guide for customer discussions and technical coordination.
Application & Industry Definition
Different applications drive specific design requirements:
- Commercial buildings - offices, malls, hotels
- Industrial - factories, workshops, food processing
- Clean environments - hospitals, pharmaceuticals, electronics
- High spaces - airports, stations, exhibition halls
- Special applications - cold rooms, labs, data centers
This determines cleanliness level, materials, filtration, and control requirements.
Airflow & Capacity Customization
Key design parameters include:
- Airflow (CMH / CFM)
- Cooling capacity (kW / TR)
- Heating capacity (hot water / steam / electric)
- Fresh air ratio (100% FA, FA + return air, recirculation)
- Optional: VAV or CAV design
- Optional: Redundant fans (duty/standby)
Cooling & Heating System Selection
Choose according to site conditions and energy strategy:
Cooling Options
- Chilled water coil
- DX coil (with compressor)
- Evaporative cooling
- Heat recovery (rotary wheel / plate exchanger / run-around coil)
Heating Options
- Hot water coil
- Steam coil
- Electric heater
- Heat pump
Filtration & Air Quality
Customized by air cleanliness requirements:
- Pre-filter: G4 / MERV 8
- Medium filter: F7-F9 / MERV 13-15
- HEPA / ULPA (cleanroom, hospital)
- Optional: Activated carbon filter
- Optional: UV-C sterilization
Humidity Control
Depending on process or comfort needs:
Humidification
- Electrode humidifier
- Steam humidifier
- Ultrasonic
Dehumidification
- Cooling coil + reheat
- Desiccant wheel
Typical industries requiring strict RH control include pharmaceuticals and electronics, while comfort HVAC applications may have optional requirements.
Fan & Motor Configuration
Fan Type
- EC plug fan
- Centrifugal fan
- Backward-curved fan
Motor
- AC motor
- EC motor (energy-saving)
Control
- VFD
- Duty/standby configuration
Casing & Structural Design
Customized for durability and installation conditions:
- Panel thickness: 50 mm/80mm
- Insulation: PU foam
- Casing material: Galvanized steel, Stainless steel (304 ), Aluminum
- Special designs: Hygienic design, Explosion-proof,
Control System & Automation
Options range from basic to smart systems:
- Stand-alone control panel
- PLC + HMI
- BMS / BACnet / Modbus integration
- Sensors: Temperature, Humidity, CO₂, Differential pressure
Installation & Layout Customization
- Horizontal / vertical AHU
- Ceiling mounted / floor mounted
- Modular or split design (for site access limits)
- Left-hand / right-hand airflow
- Noise control: Double-skin panels, Sound attenuators, Vibration isolators
The air volume handled by the unit ranges from 2,600 m³/h to 160,000 m³/h, with customizable airflow options for different clean room requirements. The unit features two major series: mixed air type (R series) and fresh air type (F series), with refrigerant media including chilled water type and direct expansion type.
Technical Advantages
Design Features
Excellent materials, unique structure, reliable performance, exceeding standards.
Reliability Measures
Premium materials ensure fundamental equipment reliability.
Temperature Maintenance
Double-layer insulated panel design with inner and outer panels available in color-coated steel, galvanized steel, or stainless steel. Aluminum alloy frame with thermal break technology and overall panel thickness of 50 mm or 30 mm.
Sealing Performance
Specialized sealing measures between all panel-to-panel and panel-to-frame junctions ensure air-tightness performance exceeding HVAC equipment standards.
Noise Reduction
High efficiency, low noise backward-curved centrifugal fans with strong overload capacity.
Antibacterial & Mold-Resistant
- Drain pan constructed from antibacterial material with continuous sterilization efficiency over 99.99%
- Optional antibacterial inner wall panels for enhanced antibacterial effect
High-Efficiency Filtration & Sterilization
Three-level filtration system (primary, medium, high-efficiency) with highest filter grade reaching H13. Composite filtration options include fiber-activated carbon filters, TiO2 sterilizers, and UV sterilizers for effective dust removal and sterilization, ensuring fresh and healthy indoor air.
Company Profile
Guangzhou Jetex-Lloyd's Machinery Ltd. is an energy-saving and environmentally friendly technology enterprise specializing in the R&D, manufacturing, sales, and service of HVAC, air handling units, and related products.
The company has been awarded honors including "National High-Tech Enterprise", "Guangdong Province Specialized & Innovative Small And Medium-Sized Enterprise", "Guangdong Province Innovative Small and Medium sized Enterprise", and "Guangdong Province Enterprise Of Observing Contract And Valuing Credit".
JETEX receives strong technical support from South China University of Technology and Guangdong Pharmaceutical University through established technical research cooperation. Our partners include numerous Fortune 500 companies and globally renowned enterprises.
