Ultra Wideband RF Power Amplifier Module 2500 to 6000MHz 50W Output Power Suitable for 5G WiFi 6 Satellite and Radar System Applications
Price:
Neg
MOQ:
1pcs
Delivery Time:
3-30days
Brand:
PTC
Product Description
Ultra Wideband RF Power Amplifier Module 2500 to 6000MHz 50W Output Power
This 2500-6000MHz RF Module is a 50W power amplifier module designed for 5G, WiFi 6, satellite, and radar system applications. The module operates without requiring an external signal source.
Key Features
- Ultra-Wideband Performance: Seamless coverage from 400MHz to 3000MHz, eliminating the need for multiple narrow-band amplifiers
- Advanced GaN Technology: Utilizes high-efficiency Gallium Nitride on Silicon Carbide (GaN-on-SiC) devices for superior power density and thermal management
- Built-in Protection: Includes integrated circuitry for over-temperature protection and VSWR (Voltage Standing Wave Ratio) protection to prevent damage from signal reflection
- Compact & Rugged: Housed in a precision-machined aluminum alloy chassis, designed to withstand harsh industrial andall relative environments
- Customizable: Frequency range and output can be customized per request
Applications
- Electronic Countermeasures (ECM): Ideal for signal jamming and broad-spectrum interference systems
- Test & Measurement: A reliable lab-grade power source for EMC testing and antenna measurements
- Communication Systems: High-power booster for 5G, Wi-Fi 6, and satellite ground stations
- Radar Systems: Pulse and CW (Continuous Wave) applications for modern radar detection
Technical Specifications
| Parameter | Specification |
|---|---|
| Frequency Range | 2500-6000MHz |
| Output Power (P_sat) | ≥50W |
| Gain | ≥50dB |
| In-band Gain Flatness | ≤5.0dB |
| Working Current | ≤5.5A |
| Connector | SMA-Female |
| Power Supply & Control Interface | DB7W2 |
| VCC Power Supply & Maximum Voltage | +28V, +32V |
| Dimension | 180×90×25mm (Not including connectors) |
| Net Weight | 1kg |
| Power Supply Wire | Red+Black+Enable wire |
| Working Temperature | -40℃ to +55℃ |
