High-Power WiFi 6E RF Jammer Amplifier Module with 50W or 100W Output for 5925-7125 MHz Signal Suppression
Price:
Neg
MOQ:
1PCS
Delivery Time:
5-30days
Brand:
PTC
Product Description
High-Power WiFi 6E 5925 - 7125MHz RF Jammer Amplifier Module with 50W 100W Output
As the wireless landscape evolves, the WiFi 6E (6GHz band) presents new security challenges. Our industrial-grade RF Jammer Module is specifically engineered to provide robust signal suppression across the entire WiFi 6E spectrum (5925-7125 MHz). Featuring high-efficiency GaN technology and a compact form factor, this module is the ideal core component for advanced signal management systems, prison security, and sensitive area protection. The 50W 6E WIFI RF amplifier module is a no signal source amplifier module, designed to be lightweight and easy to mount and carry.
Technical Specifications
| Parameter | Specifications (Standard) | Specifications (High Power) |
|---|---|---|
| Model | A6E-50W | A6E-100W |
| Frequency Range | 5925 - 7125 MHz (Full WiFi 6E Coverage) | 5925 - 7125 MHz |
| Output Power | 50W (47 ± 1 dBm) | 100W (50 ± 1 dBm) |
| Modulation Source | Digital Gaussian Noise / Analog Sweep | Digital Gaussian Noise / Analog Sweep |
| Input Voltage | DC +28V / +48V Optional | DC +28V / +48V Optional |
| Operating Current | < 6A (at 28V) | < 12A (at 28V) |
| RF Interface | N-Female (Output) / SMA (Input) | N-Female (Output) / SMA (Input) |
| Control Interface | DB9 / DB15 (Customizable) | DB9 / DB15 (Customizable) |
| Cooling System | Integrated Heat Sink (Fan cooling required) | Advanced Forced Air Cooling |
| VSWR Protection | Built-in Auto-Shutdown Protection | Built-in Auto-Shutdown Protection |
Key Features
- Cutting-Edge Frequency Coverage: Targets the latest WiFi 6E 6GHz band, ensuring no security blind spots.
- Optional Power Outputs: Choose between 50W for standard range or 100W for ultra-long-distance suppression.
- High Stability: Maintains consistent output power even in extreme temperatures (-20°C to +65°C).
- Smart Protection: Features over-temperature and high-VSWR (standing wave) protection to prevent hardware damage.
- Customization (OEM/ODM): Tailored frequency ranges, gain adjustments, and housing designs available upon request.
Product Applications
- Counter-UAV Systems: Effective against drones utilizing the 6GHz control/video downlink.
- Sensitive Facility Security: Prisons, Gas plant, and government buildings.
- Privacy Protection: Prevention of unauthorized WiFi 6E data transmission in corporate boardrooms.
Keywords: WiFi 6E Jammer, 6GHz RF Module, 100W Signal Suppressor, 50W RF Power Amplifier, WiFi 6E Security, High Power Jammer Source.
