Solid Capacity 600m3/H Discharge Distance 1500m Length 38m Sand Dredger with CE/ISO
Price:
Negotiable
MOQ:
Negotiable
Delivery Time:
Negotiable
Product Description
Solid capacity 600m3/h discharge distance 1500m length 38m sand dredger with CE/ISO
![Solid Capacity 600m3/H Discharge Distance 1500m Length 38m Sand Dredger with CE/ISO]()
3. The hull is of all welded, steel construction to give the dredger the necessary strength required for dredging operations. The side pontoons are connected to the main pontoon by means of bolts. The hull steel plate used is CCSB (marine steel plate ).
![Solid Capacity 600m3/H Discharge Distance 1500m Length 38m Sand Dredger with CE/ISO]()
Picture of the sand dredger> ![Solid Capacity 600m3/H Discharge Distance 1500m Length 38m Sand Dredger with CE/ISO]()
![Solid Capacity 600m3/H Discharge Distance 1500m Length 38m Sand Dredger with CE/ISO]()
![Solid Capacity 600m3/H Discharge Distance 1500m Length 38m Sand Dredger with CE/ISO]()
![Solid Capacity 600m3/H Discharge Distance 1500m Length 38m Sand Dredger with CE/ISO]()
Introduction to the functions of each system of dredger> ![Solid Capacity 600m3/H Discharge Distance 1500m Length 38m Sand Dredger with CE/ISO]()
![Solid Capacity 600m3/H Discharge Distance 1500m Length 38m Sand Dredger with CE/ISO]()
![Solid Capacity 600m3/H Discharge Distance 1500m Length 38m Sand Dredger with CE/ISO]()
![Solid Capacity 600m3/H Discharge Distance 1500m Length 38m Sand Dredger with CE/ISO]()
![Solid Capacity 600m3/H Discharge Distance 1500m Length 38m Sand Dredger with CE/ISO]()
![Solid Capacity 600m3/H Discharge Distance 1500m Length 38m Sand Dredger with CE/ISO]()
![Solid Capacity 600m3/H Discharge Distance 1500m Length 38m Sand Dredger with CE/ISO]()
![Solid Capacity 600m3/H Discharge Distance 1500m Length 38m Sand Dredger with CE/ISO]()
![Solid Capacity 600m3/H Discharge Distance 1500m Length 38m Sand Dredger with CE/ISO]()
![Solid Capacity 600m3/H Discharge Distance 1500m Length 38m Sand Dredger with CE/ISO]()
![Solid Capacity 600m3/H Discharge Distance 1500m Length 38m Sand Dredger with CE/ISO]()
![Solid Capacity 600m3/H Discharge Distance 1500m Length 38m Sand Dredger with CE/ISO]()
We provide sand and solid capacity 160m3/h-1500m3/h max dredging depth 8m-17m discharge distance 800m-2500m sand suction dredger>
![Solid Capacity 600m3/H Discharge Distance 1500m Length 38m Sand Dredger with CE/ISO]()
![Solid Capacity 600m3/H Discharge Distance 1500m Length 38m Sand Dredger with CE/ISO]()
1. Weifang Hairui Xinsheng Environmental Protection Equipment Manufacturing Co., Ltd., located in Qingzhou city---one of the Nine Ancient Cities in China, is leading company of China mining equipment. We are the professional manufacturer who has been dedicated in R& AMP; D, designing, producing, assembling and testing services.
The company's main products are:
3. We always insist on the principles of honesty, mutual benefit, co-development and welcome to our factory for investigation and business discussion. ![Solid Capacity 600m3/H Discharge Distance 1500m Length 38m Sand Dredger with CE/ISO]()
1. HRXS brand Cutter Suction Dredger of alloy steel disassembly struction, the non self-propelled, dismountable type, is able to dredge at any waters both in the coastal area and inland rivers.
2. The dredger can be used to excavate and transport cohesive sediment below the class III specified in code for dredging engineering construction.
3. The hull is of all welded, steel construction to give the dredger the necessary strength required for dredging operations. The side pontoons are connected to the main pontoon by means of bolts. The hull steel plate used is CCSB (marine steel plate ).
1. The hull consists of three pontoons, one main pontoon for engine room two side pontoons.
2. All parts are dimensioned to allow to be transported by road, rail or wate dredger are the dredger is powered by a Marine engine. The main engine is to drive the dredge pump and hydraulic pump.
3. Hydraulic pump will in turn power other all equipments such as cutter swing and ladder winches, and the spud rams.
2. All parts are dimensioned to allow to be transported by road, rail or wate dredger are the dredger is powered by a Marine engine. The main engine is to drive the dredge pump and hydraulic pump.
3. Hydraulic pump will in turn power other all equipments such as cutter swing and ladder winches, and the spud rams.
Picture of the sand dredger>
| 18 inch water flow 3000m3/h basic parameter | |
| Solid sand Capacity | 450-600 m3 |
| Discharge distance | 1500-2000m |
| Diesel engine power | 895kw |
| Auxiliary engine | 298kw |
| Discharge pipe diameter | 450mm |
| Cutter shaft power | 170kw |
| Dredging depth | 15m |
| Fuel tank capacity | 65000L |
| Total power | 1233KW |
| Hull steel plate | CCSB (marine steel plate) |
Introduction to the functions of each system of dredger>
| 1. | Deck plate thickness 10mm |
| 2. | Bottom plate thickness 12mm |
| 3. | Side plate thickness 10mm |
| 4. | Front plate thickness 18mm |
| 5. | Back plate thickness 18mm |
| 1. | Deck plate thickness 8mm |
| 2. | Bottom plate thickness 8mm |
| 3. | Side plate thickness 8mm |
| 4. | Front plate thickness 14mm |
| 5. | Back thickness 12mm |
| 1 | Make: | Cumins engine |
| 2 | Continuous power: | 895kw(1217HP) |
| 3 | Speed: | 1800r/min |
| 4 | Fuel consumption: | 200g/kw.h |
| 5 | Lub. Oil Consumption: | 1.0g/kw.h |
| 6 | Average fuel consumption: | 160L/H |
| 7 | Cooling system: | Water cooling |
| 1 | Auxiliary engine power: | 298kw |
| 2 | RPM: | 1800r/min |
| 3 | No.of cylinders: | 6 |
| 4 | Fuel consumption: | 200g/kw.h |
| 5 | Full power fuel consumption: | 53L/H |
| 6 | Cooling system: | Water cooling |
| 1 | Make: | JICHAI, Jinan, China |
| 2 | Model: | YOTFJBX650-35Fsh |
| 3 | Input speed: | 1650r/min |
| 4 | Transmission efficiency: | >or= 97% |
| 5 | Working oil temperature: | <or=110ºC |
1 | Make: | Hangzhou, China |
| 2 | Model: | 3P500 |
| 3 | Ratio: | 1.1:1 |
| 4 | Cooling ways: | Water cooling |
| 1 | Make: | Shijiazhuang Industrial Pump, China |
| 2 | Model: | Wn450 |
| 3 | Dredge pump water flow(cubic metre per hour): | 3000cbm/hr |
| 4 | Sand or solid capacity: | 3000cbm/hr |
| 5 | Diameter of suction: | 600mm |
| 6 | Diameter of discharge: | 450mm |
| 7 | Head: | 67m |
| 8 | Pump shaft power: | 770kw |
| 1 | Ladder lifting winch: | 1 set |
| 2 | Swing winch: | 2 sets |
| 3 | Diameter of drum: | 475mm |
| 4 | Working pressure: | 16Mpa |
| 5 | Wire rope speed: | 0-30m/min |
| 1 | Make: | Yongli, China |
| 2 | Diameter: | 1800mm |
| 3 | Cutter shaft power: | 170kw |
| 4 | Cutter teeth quantity: | 40 |
| 5 | Cutter blade quantity: | 5 |
| 1 | Make | FURI |
| 2 | Model | SVH224 |
| 3 | Power | 30kw |
| 1 | Capacity | 50KN |
| 2 | Lift diameter/outreach | 4m |
| 1 | Type | Lips type |
| 2 | Anchor weight | 960kg |
| 3 | Anchor quantity | 2 |
We provide sand and solid capacity 160m3/h-1500m3/h max dredging depth 8m-17m discharge distance 800m-2500m sand suction dredger>
| Model | Sand and solid capacity | Max. dredging depth | Discharge distance |
| HRXS-200 | 160m3/h | 8m | 800m |
| HRXS-250 | 200 m3/h | 9m | 1000m |
| HRXS-300 | 300 m3/h | 10m | 1200m |
| HRXS-350 | 400 m3/h | 11m | 1500m |
| HRXS- 400 | 500 m3/h | 13m | 1500m |
| HRXS-450 | 600 m3/h | 14m | 1500m |
| HRXS-500 | 800 m3/h | 15m | 2000m |
| HRXS-550 | 900 m3/h | 16m | 2000m |
| HRXS- 600 | 1100 m3/h | 16m | 2000m |
| HRXS-650 | 1200 m3/h | 16m | 2100m |
| HRXS-700 | 1400 m3/h | 17m | 2200m |
| HRXS-800 | 1500 m3/h | 17m | 2500m |
| Remark: HRXS brand cutter suction dredger can offer the water flow from 800 cubic meter to 15000 cubic meter ,also according to customers requirement to customized all standard and non standard dredging cutter suction dredger with the other power cutter suction dredger | |||
Packaging&Shipping:
We ship in containers or bulk carriers. The sand suction dredger is usually shipped to your country by sea. We will cover the hull with plastic film to prevent corrosion and damage to the hull caused by rain or sea water, and fix the plastic film with special ropes to ensure the integrity of the goods during transportation.
We ship in containers or bulk carriers. The sand suction dredger is usually shipped to your country by sea. We will cover the hull with plastic film to prevent corrosion and damage to the hull caused by rain or sea water, and fix the plastic film with special ropes to ensure the integrity of the goods during transportation.
| 1 | Wide range of use applications. |
| 2 | High efficiency Large output Long pump distance Low fuel consumption. |
| 3 | Rexroth Vickers full hydraulic control. |
| 4 | Siemens PLC is easy to operate. |
| 5 | Engine choice from Weichai. And more. |
| 6 | Equipped with Australian technology dredge pump. |
| 7 | The modular design enables fast assembly with HID seniors engineers. |
| 8 | Dredger components available in factories to allow short delivery times. |
| 9 | Control the working process of dredging and pumping. Delivering dredged materials. lower cost. |
| 10 | Follow manufacture guideline: CCS-ZC standard. |
| 11 | CE ISO certificates acquired to prove high quality. |
| 12 | Western Dredge brand parts. Easy to find globally. |
| 13 | Can choose reliable Chinese brand parts to lower costs. |
| 14 | Gain access to our sales team. Design team, manufacture team 24/7. |
| 15 | Lifetime Technical Assistance. |
