Microwave Disinfection Medical Waste Disposal Treatment Management
1. Incinerator description :
1.Medical waste is pre-wet by a water spray system 2.Water - cooled microwave generator is used,cooling medium is antifreeze 3.The door of microwave disinfection equipment adopts conductive sealing strip + anti-flow groove double sealing structure and is equipped with an interlock system to prevent microwave leakage 4.The inner liner and the inner side of the door are made of 304 stainless steel,which is durable 5.Equipped with a special garbage can made of PTFE material, which has good wave permeability and can be disinfected together with the garbage can 6.Equipped with waste gas treatment device, including high efficiency filter, activated carbon filter, high efficiency filter used to deal with the microorganisms contained in the waste gas, filter particle size 0.2μm, can filter out almost all microorganisms, activated carbon filter for deodorization. |
Medical waste microwave disinfection equipment is a kind of
medical waste disinfection equipment using the dual function of
microwave and steam, the equipment first make water
prehumidification to medical waste , use microwave thermal effect
to heat prehumidified water to generate steam and medical waste
containing polar molecules at the same time, and then by the
sensitivity of bacteria to temperature sterilization, microwave also
has non-thermal effect.Non-thermal effect refers to other microbe
killing effects except thermal effect, which is the unique effect of
microwave sterilization. The heating process of the equipment is
also the process of disinfection. The disinfection room is kept for 45
minutes after reaching 95 degrees or above to complete
disinfection.
1.Medical waste is pre-wet by a water spray system
2.Water - cooled microwave generator is used,cooling medium is antifreeze
3.The door of microwave disinfection equipment adopts conductive sealing strip + anti-flow groove double sealing structure and is equipped with an interlock system to prevent microwave leakage
4.The inner liner and the inner side of the door are made of 304 stainless steel,which is durable
5.Equipped with a special garbage can made of PTFE material, which has good wave permeability and can be disinfected together with the garbage can
6.Equipped with waste gas treatment device, including high efficiency filter, activated carbon filter, high efficiency filter used to deal with the microorganisms contained in the waste gas, filter particle size 0.2μm, can filter out almost all microorganisms, activated carbon filter for deodorization.
2.Water - cooled microwave generator is used,cooling medium is antifreeze
3.The door of microwave disinfection equipment adopts conductive sealing strip + anti-flow groove double sealing structure and is equipped with an interlock system to prevent microwave leakage
4.The inner liner and the inner side of the door are made of 304 stainless steel,which is durable
5.Equipped with a special garbage can made of PTFE material, which has good wave permeability and can be disinfected together with the garbage can
6.Equipped with waste gas treatment device, including high efficiency filter, activated carbon filter, high efficiency filter used to deal with the microorganisms contained in the waste gas, filter particle size 0.2μm, can filter out almost all microorganisms, activated carbon filter for deodorization.
| No. | System unit | Item | Technical parameters | |||
| Model | ZT-MWT-10 | ZT-MWT-20 | ZT-MWT-30 | ZT-MWT-50 | ||
| 1 | Stock bin | Volume | 100L | 200L | 300L | 500L |
| Material | Stainless steel + alloy steel | Stainless steel + alloy steel | Stainless steel + alloy steel | Stainless steel + alloy steel | ||
| 2 | Crushing system | Power | 5.5kw | 5.5kw | 7.5kw | 11kw |
| 3 | Sterilization chamber | Power | 1.5kw | 3.3kw | 4.5kw | 4.5kw |
| 4 | Main body dimension | 2000*1500*1800 | 2100*1500*1800 | 2200*1680*1840 | 2300*1800*1840 | |
| 5 | Supporting facility | Steam generator, water chiller, water softener, electric control box, exhaust equipment (optional) | ||||
| 6 | Total power | 12kw | 14.8kw | 18kw | 21.5kw | |
| 7 | Capacity(kg/h) | 10 | 20 | 30 | 50 | |
Design feature :
| 1 | Light aluminium alloy fan part. |
| 2 | High performance centrifugal fan. |
| 3 | Combustion air inlet with device to adjust the air flow. |
| 4 | Automatically closing air gate |
| 5 | Sliding boiler coupling flange to adapt the head protrusion to the various types of boilers. |
| 6 | Monophase electric motor to run fan and pump. |
| 7 | Gear pump with pressure regulator and fuel stop-cock valve. |
| 8 | Sequence controller - EN 230.. |
| 9 | Photo resistance flame scanner. |
| 10 | 7pole outlet for burner electrical and thermostat supply. |
| 11 | Electrical plant protection rating IP40. |
| 12 | Sound-proof plastic protective cover. |
| 13 | Adjustable blast-pipe with nozzle and deflector disk in steel. |
| 1 | Gasified pyrolysis incineration is used for burning many kinds of waste. |
| 2 | Both gas-motivated and oil-motivated are all can be preferred according to customers' needs. |
| 3 | Daily waste can be burned once by gasified incineration. |
| 4 | Gasified incineration, mixed incineration and burnout treatment ensures low emission standard of dust, dioxin etc.. |
| 5 | Totally enclosed operation is suitable for treating infectious waste to avoid secondary pollution. |
| 6 | Compact structure and small land occupation. |
| 1 | Hospital medical waste: Bandage. Paper/ Injection Syringe/ Drop Bottle.expired drugs. infectious viscera.etc. |
| 2 | Infectious diseased animal body/fur/hair.widely used in pets carcasses disposal: pig. dog. cat, fish. chicken. cattle. duck. etc. |
| 3 | Domestic daily home waste. |
| 4 | E-waste. |
| 5 | Some other industrial waste. |
| ZHITE Environmental Protection Technology Co., Ltd.is a comprehensive domestic enterprise with integrating scientific research and development,engineering design,production and installation and commissioning services.The main products are medical waste treatment equipment,diseased livestock and poultry harmless treatment equipment,household waste treatment equipment,kitchen waste treatment equipment,tail vegetable treatment equipment,sludge treatment equipment and all kinds of shredding equipment and other solid waste treatment products. Also can design and customize all kinds of efficient and practical equipment and production lines according to customer needs.      |
