The IDU 905 is the indoor unit for an OptiX RTN 905 system. It receives and multiplexes services, performs service processing and IF processing, and provides the system control and communications function.
The Huawei 6–42 GHz traditional frequency IP microwave has a maximum of 2 Gbit/s per carrier and 16 Gbit/s per antenna ultra-large transmission capacity, it is the industry’s first IP microwave that supports TDM/Hybrid/Packet/Routing services on the unified platform, satisfying the requirements of large-capacity IP service transmission and IP-based evolving of traditional PDH/SDH microwave. The solution provides a flexible architecture that can be deployed in split, full-outdoor, or full-indoor scenarios. It features high reliability and end-to-end unified O&M management. It is widely used in broadband wireless transmission in vertical sectors, such as government, broadcasting, oil & gas, education, and electric power.
HW Optix Rtn 905F Indoor Split Type Ip Microwave Equipment for Seamless Connectivity
Price:
$1,335.40/sets 2-49 sets
MOQ:
2 sets
Delivery Time:
Negotiable
Brand:
HW
Product Description
PRODUCT DESCRIPTION
Split Type Long Range Microwave Transmission Equipment Assembly IDU RTN 905F
All new Products Not Used Products！
TECHNICAL SPECIFICATION
Network layer | Suitable for: access layer and aggregation layer |
Frequency band | 6 ~ 42 GHz |
Channel spacing | 3.5/ 7/14/28/40/56/112 MHz |
Bandwidth | Determine based on ODU bandwidth |
Modulation mode | QPSK Strong，QPSK，16QAM Strong，16QAM，32QAM， 64QAM，128QAM， 256QAM，512QAM，512QAM Light， 1024QAM，1024QAM Light，2048QAM， 4096QAM |
Maximum number of RFUs | Based on the RTN905F technical specifications |
RF direction | 12 |
Air port capacity | Single carrier 1166~2500 Mbit/s (non XPIC) |
Exchange capacity | 90 Gbit/s (using CSHOF), 10 Gbit/s (using CSHO) |
TDM crossover capacity | 32×32 VC-4 |
Link aggregation | 2-4 |
Interface type | E1，T1，STM-1（e/o），FE（e/o），GE（e/o）， 2.5GE（o） ，10GE（o） |
Describe | OptiX RTN 905F basic configuration unit 4 * GE (RJ45)+2 * GE (SFP)+4 * 10GE (SFP+)+2 * STM-1 (SFP)+16 * E1+2 intermediate frequency unit IDU module (-48VDC) -2F with IDU installation accessories |
Super dual frequency | Based on the RTN905F technical specifications |
L3 VPN | Based on the RTN905F technical specifications |
eCPRI support | Based on the RTN905F technical specifications |
Rf configuration mode | N+0 N×（1+0） 1+1 N+1 XPIC 2 × 2 CA 4 ×4 MIMO |
Feature | Ethernet II, IEEE 802.3 and IEEE 802.1q/p field addition/deletion, and VLAN label exchange (IEEE 802.1q/p) ISIS, OSPF, BGP, RSVP, LDP Support for flow control (IEEE 802.3x) Support Link Aggregation Group (IEEE 802.3ad LAG and L1 LAG) RMON (IETF RFC 2819) |
Business type | Native ETH service: E-Line dedicated line service and E-LAN private network service PW based Native ETH services: E-Line dedicated line services, Ethernet aggregation services, E-LAN private network services (VPLS, representing virtual private network services) L3VPN, L2VPN (VLL), CES, MCE |
Key characteristics | CES E1, IEEE 1588v2, USB start, H-QoS, PLA/EPLA/EPLA+, AES-256 encryption, device anti-theft, 1+1, N+1, XPIC, AM, TDM, PWE3/MPLS, SDB, L3VPN, CA, MIMO |
Antenna | Parabolic antenna: 0.3m~3.7m |
IDU Weight | 5.4 kg（1+0） 6.2 kg（1+1） |
IDU Specification | |
Environment | Temperature: IDU -5 °C ~+60 °C ； ODU -33 °C ~ +55 °C Humidity: IDU 5%~95%； ODU 5%~100% |
Power source | -38.4 V~-57.6 V |
Certificate | CE、RCM、 FCC、IC、ETL、MCMC |
