Customized Cumins 582 Kw Full Automatic 16 Inch Diesel Engine Cutter Suction Dredger
Price:
Negotiable
MOQ:
1 set
Delivery Time:
Peak Season Lead Time: 1-3 months, Off Season Lead Time: one month
Product Description
Full automatic diesel engine 16 inch cutter suction dredger
Cutter Suction Dredger is self-propelled or non self- pro-pelled. portable cutter suction dredger.Hull can be dis-mantled and re-assemble easily with box structure.Equipped with horizontal shifting devices.cutter ladder lifting devices. spud devices. deck crane and so on.Widely used in sand-excavating.river dredging. desilt-ing.Reclamation for channels and land port construction. etc.
Mainly features:
| 1 | Cutter suction dredger is suitable for inland waterways. lakes. rives of dredging. |
| 2 | Standard design. allowing early delivery and low price. |
| 3 | Cutter suction dredger has advantages of high output. low cost and convenent rapare. |
| 4 | Completely assembled and fully tested before delivery. |
| 5 | Cutter suction dredger adopt hydeaulic system. this system is very steady. it isn't easy to appear failure. |
| 6 | Simple rapid assembly and dismantling. |
| 7 | Ready for operation on arrival at site. |
| 8 | Dredging pump adopt diesel engine to transmission.the power is stonger and steady. |
| 9 | Spare parts available from stock. |
| 10 | Transportable by road. rail or sea. |
| 11 | Reliable hydraulic system. |
| 12 | Efficient fuel consumption. |
16 inch dredger image:
Cutter suction dredger has broad range of applications in operations in the rivers . lakes. seas for the dredging.
channel excavation. In exceptional circumstances a cutter suction dredger cutter installed on the highpower.devices.
can be excavated without blasting rocks such as basalt and limestone strata.With characteristics of high efficiency.
large output up to several thousand cubic meters per hour.the sand.or crushed rock material to rely on a strong
driving force the mud pumps and mud pipeline, pumping out a few kilometers outside.
Detailed parts introduce :
All parts on my cutter suction dredger adopts reliable and durable international brand to reach the low failure high efficient. Offering the biggest profit for customers.
Best parts will be used for the dredgers, like world famous Cumins engines, Shijiazhuang pumps, Hangzhou gearboxes, Simens PLC control system.
Hydraulic system is one of the most important parts of cutter suction dredgers. The cutter head, ladder winch, swing winches, spud or spud carriage are driven by hydraulic motors for higher efficiency and durability. Reputed brands are used for the other hydraulic parts like hydraulic pipes, hydraulic pumps, hydraulic valves.
16 inch dredger basic information :
| Dredger Loa | 32.0m |
| Hull Size(L*B*H) | 19.0×7.5×2.0m |
| Main pontoon(L*B*H) | 13.8×3.5×2.0m |
| Side Pontoon(L*B*H) | 19.0×2.0×2.0m |
| Structure | Box-structure |
| Main Engine Brand&Power | Cumins 582kw/Jichai 540Kw |
| Auxiliary enging power | Cumins 224kw |
| Harbour Generator | Cumins 30kw/Jichai 30kw |
| Total Power | Cumins 836kw/Jichai 790kw |
| Dredging Pump | Warma Technology |
| Discharge Pipr Inner Dia. | 400mm |
| Head | 45m |
| Max.Dredging Depth | 13m |
| Water Flow | 2500m³/h |
| Solid Sand Capacity | 500m³/h |
| Cutter head diameter | 1450mm |
| Cutter head power | 108kw |
Dredger at installation site :
Dredger packing and transportation :
Our service :
| 1 | offer the solution and design before the sale. |
| 2 | Inquiry and consulting support. |
| 3 | Sample testing support. |
| 4 | View our Factory. |
| 5 | Training how to instal the machine, training how to use the machine. |
| 6 | Engineers available to service machinery overseas. |
Our customer:
Company overview:
| 1 | More than 25 years experience |
| 2 | More than 120 certificated engineers and technicians |
| 3 | Cooperated with famous ship design & research institute and Ocean University |
| 4 | Exported to more than 80 countries in all over the world |
Question for customer:
| 1 | The capacity of the output per hour? |
| 2 | The max.dredging Depth ? |
| 3 | The max. discharge distance ? |
