Spud Carriage High Speed Sand Pump Cutter Suction Dredger for Large-scale Dredging
Price:
Negotiable
MOQ:
1 set
Delivery Time:
Peak Season Lead Time: 1-3 months, Off Season Lead Time: one month
Product Description
Small cutter suction dredger with river sand pump
About Set sail cutter suction dredger: | Set Sail hydraulic cutter suction dredger can apply to all kinds of geologic structures and can be widely used in mineral digging river dredging lake dredging port dredging and reclamation works. absorbing advanced technology of Dutch related products. this series of dredgers show their feature of resonable design. all hydraulic control. simple operation. little maintenance and strong power. The capacity of dredgers ranges from 300 m3/hr to 10000 m3 per hour dredging depth from 4 m to 30 m and discharge distance from 300 m to 4000 m, which can satisfy different dredger work demands. |
Basic type :
| Model | QHCSD150 (6inch) | QHCSD200 (8inch) | QHCSD250 (10inch) | QHCSD300 (12inch) | QHCSD350 (14inch) | QHCSD450 (18inch) | QHCSD500 (20inch) | QHCSD600 (24inch) |
| Dimensions (L*W*H)m | 25*4.7*1.26 | 26*5.3*1.5 | 32.5*5.3*1.5 | 33*6.6*1.8 | 35*6.8*2 | 37*7.9*2.2 | 39*9*2.5 | 42*10*2.8 |
| Dredging Depth | 12m | 12m | 15m | 15m | 15m | 20m | 20m | 20m |
| Water Capacity | 600m3/h | 800 m3/h | 1600 m3/h | 2500 m3/h | 3000 m3/h | 4000 m3/h | 5000 m3/h | 5500 m3/h |
| Discharging Distance | 800m | 1000m | 1200m | 1500m | 2000m | 2000m | 2500m | 2500m |
| Total Weight | 29t | 38t | 55t | 82t | 110t | 180t | 210t | 300t |
| Remark: all of cutter suction dredging equipment are customized product . we can do the most water flow can reach the 20000 cubic meter . | ||||||||
Product in workshop:
Dredger at working site :
Set Sail cutter suction dredger advantage :
| 1 | Specially -made cutter head structure . it can meet different working condition and add the concentration . |
| 2 | Our factory can made large number of big capacity cutter suction dredger more than water flow 20000 cubic meter |
| 3 | Specially -made structure of the dredger . such as full electric power and only one underwater structure . |
| 4 | Really import devices from the abroad on the dredger such as Rexroth hydraulic system |
| 5 | All the steel plate can reach the CCSB standard . advanced manufacture device for the all each step |
Spare part :
| 1. Cummins diesle engine . stable performance . long continue working time . convient after sales service |
| 2. Hydraulic cutter head . different of cutter teeth shape can meet the different working condition . specially-made blade can add the capacity . |
| 3.Hydraulic pump . |
| 4.Sand pump : Shijiazhuang industiral factory. |
Customer visited our factory :
About Set Sail factory:
Qingzhou Setsail Dredging Machinery Equipment Co., Ltd. is professional in manufacturing the dredgers, weed harvesters. mining machinery so on dredging equipment . The products have many series, including 500-20000m³/h large scale dredging and sand mining equipment. gold panning ship. sand transportation ship. multi-function service work boat . protection boat .etc..which widely used in sand-excavating. river dredging. channel maintenance and broaden desilting blowing land reclamation port construction cleaning the river etc. All the products can be customized according to client's requirements and formed a complete ship machinery industry chain.
Cutter suction dredger are exported to more than 40 countries. such as Bangladesh. Brazil. Egypt. Nigeria. Indonesia. Philippine. etc. Under advance technology. stable and reliable quality.good after-service. Head dredging has obtained the honors from the domestic and abroad customers.
Cutter suction dredger focus on product leadership.service.cost. safety and efficiency, which will continue to enable us to devote ourselves in heavy industry. We will continuous invest in manpower material resources and technical service to help our customers solving dredging work. water cleaning project. mining separation job etc.
Factory certification :
Contact information :
