21.5 Inch Industrial Panel PC with Capacitive Touch Display and Wide Temperature Support in Full Aluminum Alloy

Price Negotiable

Price: $300-480

MOQ: 1

Delivery Time: 5-8 Works days

Brand: Smatipc

Product Description

Full Aluminum Alloy Panel PC - 21.5 Inch Industrial Touch Display

Key Features

21.5" Industrial-Grade Touchscreen with IP65 Protection - Features robust front panel with IP65 dust and water resistance, available with high-sensitivity resistive touchscreen (50 million-touch lifespan) or optional capacitive screen
Rich I/O Ports & Flexible Connectivity - Comprehensive interfaces including 4× USB, 2× COM (RS232/485, expandable to 6), 2× LAN, 1× HDMI, and Wi-Fi support
Stable 24/7 Operation with Wide-Temperature Support - Designed for continuous operation from 0°C to 50°C (with wide temperature screen support: -20°C to 60°C)
High-Performance Processor & Custom OS Compatibility - Runs Windows by default with support for Linux, Ubuntu, and other custom systems
Compact & Easy to Install - Slim, space-saving all-in-one design with VESA mount support

Technical Specifications

Model	ITPC-C215
Color	Gray (color customizable)
Material	Aluminum alloy shell
Processor	Intel Celeron J1900, 3rd/4th/5th Gen Intel Core i3/i5, 6th/7th/8th Gen Intel Core processor
Memory	DDR3/DDR4 laptop memory slots, Max. 32GB
BIOS	AMI BIOS
Display Chip	Intel UHD Graphics
Display Port	1× HD, 1× LVDS
Storage	1× mSATA hard disk
Expansion Slot	2× Mini PCIE slots (support WIFI/Bluetooth/3G/4G with SIM card holder)
I/O Ports	1× HD, 2× COM (COM1-2 RS232/485, customizable to 6 COM), 1× Power Button, 1× DC, 1× audio two-in-one, 4× USB, 2× Realtek Gigabit network ports
Other Functions	Power on, timer on, watchdog (0~255 level)
Expansion Options	GPIO (4 channels), 4× COM, 2× USB (standard shipment does not include)
Screen Size	21.5 inch TFT-LCD
Brightness	250 cd/m²
Viewing Angle	Full Angle
Ratio	16:9
Resolution	1920×1080
Touch Screen	Industrial capacitive touch screen, 50+ million touch lifespan
Speaker	2× 8Ω 2W speakers
Input Voltage	DC 12V input, customizable DC 9~36V wide voltage input
Work Temperature	-20℃ to +60℃ (solid state drive), surface air flow
Work Humidity	5% to 95% non-condensable state
Dimension	540 × 332 × 78 mm
Embedded Size	528 × 320 mm
Weight	7.6 kg
Application	Industrial automation, medical, logistics and transportation, warehousing, machine vision, etc.
