N150 Compact Industrial Grade Mini PC With DDR5 RAM And Dual M.2 SSD For Industrial Automation

Price Negotiable

Price: US $168-188

MOQ: 1

Delivery Time: 5-8 Work Days

Brand: SMATiPC

Product Description

Iwill Small Fanless PC - Quad Core N150 Industrial Mini PC

Compact industrial-grade mini PC featuring Intel N150 processor, DDR5 memory, dual M.2 SSD support, and dual gigabit Ethernet for demanding industrial applications.

Iwill N150 Industrial Mini PC front view

Iwill N150 Industrial Mini PC rear ports

Iwill N150 Industrial Mini PC internal components

Iwill N150 Industrial Mini PC connectivity options

Iwill N150 Industrial Mini PC installation example

Iwill N150 Industrial Mini PC industrial application

Iwill N150 Industrial Mini PC detailed view

Iwill N150 Industrial Mini PC expansion slots

Iwill N150 Industrial Mini PC VESA mount

Technical Specifications

Model	Nano-N1522
Color	Metal ash (color can be customized)
Material	High quality all aluminum alloy
Processor	Intel Twin Lake N150, 4 cores 4 threads
BIOS	AMI EFI BIOS
Memory	1 DDR5 4800MHz SODIMM memory slot, up to 16 GB
Storage	2 × M.2 2280 slots, 1 × 2.5 inch HDD/SSD
Display Chip	Intel Graphics
Display Port	2 × HD
I/O Port	1 × Power Switch, 4 × USB 3.2, 2 COM (RS232/RS485), 1 × DC, 2 × HD, 4 × USB 2.0, 2 × RJ45 network ports, 1 × audio two-in-one port
Expansion Slots	1 × M.2 2280 M-key slot 1 (PCIE3.0 X1 & SATA) 1 × M.2 2280 M-key slot 2 (PCIE3.0 X1 protocol) 1 × MINI PCIE slot (PCIE & USB2.0 signals, optional WIFI/4G), built-in SIM card slot Expandable port (not included in standard shipment): 4 GPIO, 1 USB2.0
Network	2 × RTL8111H 10/100/1000M Gigabit Ethernet
Other Functions	Auto power on, Timing boot, Wake on LAN, PXE boot, watchdog (level 0~255)
Power Supply	DC 12V input
Operating Temperature	0℃ to +40℃ (commercial HDD), -20℃ to +50℃ (industrial SSD), surface air flow
Operating Humidity	5% ~ 95% non-condensable state
Dimensions	150 × 126.5 × 45 mm
Weight	0.84 kg

Industrial Applications

Industrial control, industrial automation, robotics, Internet of Things, edge computing, machine vision, AGV/AMR, and other demanding industrial environments.

Shipping & Delivery Information

Delivery Time: 1-3 Days for one sample, 15 Working days for large quantities.

Packaging: Each unit packaged in neutral box.

Shipping Methods: For small quantities: DHL, Fedex, UPS. For large quantities: air or sea freight available.
