BV Approved Hydraulic Cutter Suction Dredger With WN500 Sand Dredging Pump Sand Sludge Dredging From Port Sea And River
Product Description:
The Cutter Suction Dredger comes in a range of colors to suit the customer's preference. Whether you
want a bold and striking design or something more subdued, we can customize the color to suit your needs.
The Cutter Suction Dredger is ISO certified to ensure that it meets the highest standards of quality and
safety. Our ISO certificate is available up to 207, ensuring that our customers get the best product possible.
The discharge diameter of the Cutter Suction Dredger is 20 inches, which makes it perfect for handling large
volumes of material. This feature allows for more efficient dredging, which translates into reduced time and
costs for the user.
The dredger also comes with 5-6 pieces of cutter blades in the crown type. This feature makes it possible
to cut through tough materials and get the job done quickly and efficiently. The cutter suction dredge is
perfect for construction projects, mining operations, and other industrial activities that require the removal
of large volumes of material from water bodies.
| YSCSD600 solid capacity 1050 cbm/h hydraulic cutter suction dredger | |
| Technical specifications | |
| Water flow | 6,000 m3/h |
| Solid capacity | 1050 cbm/h |
| Max. dredging depth 45° | 15 m |
| Discharge distance | 2,000 m |
| LOA | 48 m |
| Dredger after assembly | 48*9.4*2.8 m Length* width* depth |
| Dredger structure | Dismantle type and can be assembly in working site |
| Average draught | 1.8 m |
| Diameter discharge pipe | 600 mm/24 inch |
| Main Engine | 1,715 kw Cummins engine |
| Rotate speed | 1800 r/min |
| Auxiliary engine power | 746 kw Cummins engine |
| Generator | 50 kw |
| Hydraulic cutter power | 440 kw |
| Total power | 2,511 kw |
Features:
- Product Name: Cutter Suction Dredger
- Optional: Spud Carriage, Anchor Boom
- Discharge Diameter: 20inch
- R&D Department: Available
- Sand Pump: WN500
- Color: Customer's Request
- Features:
- Hydraulic Cutter Suction Dredger
- Cutter Head Dredger
Applications:
It is a non-self propelled hydraulic cutter suction dredger that is built to the highest standards in China and
certified by CCS. The dredger is equipped with a powerful hydraulic system made by Rexroth, making it
highly efficient and reliable in its operations.
The Yongsheng dredger YSCSD600 is suitable for a wide range of applications. It can be used in the
construction of ports, harbors, and waterways. It is ideal for dredging deep waterways and channels,
as well as for land reclamation projects.
The dredger is also suitable for use in the mining industry, where it can be used to extract minerals from
the seabed. It is also used in the oil and gas industry to maintain pipelines and offshore structures.
The Yongsheng dredger YSCSD600 is a high-quality product that is custom-built to meet the needs of the
customer. The minimum order quantity is 1, and the price is based on custom building. The dredger can
be delivered in a container or in bulk, depending on the customer's requirements.
The delivery time for the Yongsheng dredger YSCSD600 is 60 days, and the payment terms are 40% deposit
and 60% final payment. The supply ability is 30 sets, and the product is backed by an R&D department that
is available to provide support and advice.
The dredger is also available with a Panama certificate, which is essential for those who operate in
international waters. It is a reliable, efficient, and durable hydraulic cutter suction dredger that is designed
to meet the needs of a wide range of customers.
Customization:
Support and Services:
-Technical consultation and advice
-Installation, commissioning, and training
-Maintenance and repair services
-Spare parts supply and management
-Upgrades and retrofits
-24/7 remote support and troubleshooting
Our team of experienced technicians and engineers are dedicated to providing exceptional support
and service to our customers, helping them get the most out of their Cutter Suction Dredger investment.
Packing and Shipping:
Product Packaging:
- The Cutter Suction Dredger will be securely packed in a wooden crate to ensure safe transportation.
- All necessary parts and accessories will be included in the package.
- The package will also include a user manual for easy installation and operation.
Shipping:
- Shipping will be arranged by our logistics team and delivery will be made to the address provided by the customer.
- The shipping cost will be calculated based on the destination and weight of the package.
- The estimated delivery time will be provided to the customer once the order is confirmed.
- The customer will receive a tracking number to monitor the delivery status of the package.
