Product Description
PVC pipe production line / PVC tube making machine
Description of PVC pipe makign machine
PVC pipe extruder machine/UPVC pipe making machine is mainly used in the manufacturer of the UPVC and PVC pipes with various tube diameters and wall thickness such as agricultural and constructional plumbing, water supply and drain etc. This set is composed of conical twin-screw extruder,vacuum calibration tank, hual-off machine,cutter, stacker etc.
Our machine can produce the PVC pipe with diameter from 16-630mm.
Main parameter of PVC pipe making machine
Machine details ![Plastic Water Drainage PVC Pipe Making Machine]()
![Plastic Water Drainage PVC Pipe Making Machine]()
![Plastic Water Drainage PVC Pipe Making Machine]()
![Plastic Water Drainage PVC Pipe Making Machine]()
![Plastic Water Drainage PVC Pipe Making Machine]()
![Plastic Water Drainage PVC Pipe Making Machine]()
![Plastic Water Drainage PVC Pipe Making Machine]()
Our customer&exhibition
![Plastic Water Drainage PVC Pipe Making Machine]()
![Plastic Water Drainage PVC Pipe Making Machine]()
Description of PVC pipe makign machine
PVC pipe extruder machine/UPVC pipe making machine is mainly used in the manufacturer of the UPVC and PVC pipes with various tube diameters and wall thickness such as agricultural and constructional plumbing, water supply and drain etc. This set is composed of conical twin-screw extruder,vacuum calibration tank, hual-off machine,cutter, stacker etc.
Our machine can produce the PVC pipe with diameter from 16-630mm.
Main parameter of PVC pipe making machine
| Model | pipe range(mm) | extruders | max.speed(m/min) | total power(kw) | max.output(kg/h) | line length(m) |
| PVC-50*2 | 16-50 | SJSZ51/105 | 6 | 60 | 150 | 20 |
| PVC-63 | 16-63 | SJSZ45/90 | 10 | 45 | 120 | 20 |
| PVC-110 | 50-110 | SJSZ51/105 | 6 | 60 | 150 | 24 |
| PVC-160 | 63-160 | SJSZ65/132 | 5 | 100 | 300 | 24 |
| PVC-250 | 110-250 | SJSZ80/156 | 3.5 | 120 | 400 | 28 |
| PVC-315 | 160-315 | SJSZ80/156 | 3 | 160 | 400 | 36 |
| PVC-450 | 250-450 | SJSZ92/188 | 1.5 | 200 | 700 | 36 |
| PVC-630 | 315-630 | SJSZ92/188 | 0.9 | 230 | 700 | 36 |
Machine details
SPIRAL AUT LOADER
1. MOTOR POWER: 2.2 KW
2. LOADING CAPACITY: 600 KG/H
3. MATERIAL : SS304
4. LENGTH OF THE SS PIPE: 4.5 M / COMTOMERIZED
5. SUITABLE MATERIAL: PVC POWDER
1. MOTOR POWER: 2.2 KW
2. LOADING CAPACITY: 600 KG/H
3. MATERIAL : SS304
4. LENGTH OF THE SS PIPE: 4.5 M / COMTOMERIZED
5. SUITABLE MATERIAL: PVC POWDER
SJSZ 65/132 twin conical screw extruder
1. double screw feeder 1.5 kw
2. main motor : 37 kw
3. gear box brand: JIANGYIN
4. screw barrel brand: Demaji / Guangming
5. cooling type: fan cooling
1. double screw feeder 1.5 kw
2. main motor : 37 kw
3. gear box brand: JIANGYIN
4. screw barrel brand: Demaji / Guangming
5. cooling type: fan cooling
control panel
1. inverter brand: ABB / SIEMENS / DELTA
2. contactors / relays: siemens
3. air switch: siemens
4. temperature control meter: Omran
1. inverter brand: ABB / SIEMENS / DELTA
2. contactors / relays: siemens
3. air switch: siemens
4. temperature control meter: Omran
die
1. heater: ceramic heater
2. heating power: 25 kw
3. pvc pipe size: 3-8 inch
4. with support frame
1. heater: ceramic heater
2. heating power: 25 kw
3. pvc pipe size: 3-8 inch
4. with support frame
vacuum tank:
1. vacuum pump: 5.5 kw
2. water pump power: 4 kw
3. vacuum tank length: 6000 mm
4. tank material: ss304
5. frond & back movement: 600 mm
6. all fitting material: SS304
1. vacuum pump: 5.5 kw
2. water pump power: 4 kw
3. vacuum tank length: 6000 mm
4. tank material: ss304
5. frond & back movement: 600 mm
6. all fitting material: SS304
HAUL OFF
1. 3-CLAW HAUL OFF
2. MOTOR POWER: 4 KW
3. ELECTRICAL PARTS: SIEMENS
1. 3-CLAW HAUL OFF
2. MOTOR POWER: 4 KW
3. ELECTRICAL PARTS: SIEMENS
CUTTER
CUTTING RANGE: 3-8 INCH
CUTTING RANGE: 3-8 INCH
Our customer&exhibition
