Natural Finish Dl Tinned Aluminum Tube Cable Terminal Lug with Injection Molding Process
Product Description
DL tinned aluminum tube cable terminal lug
Material: Aluminum, Good conductivity
Marking: The marking should be clearly, well-proportioned
Surface Treatment: Acid cleaning, bright or tin plated
Product Property: It is used to connect the Aluminum conductor end
![Dl Tinned Aluminum Tube Cable Terminal Lug]()
| Type No | Main Dimensions(mm) | |||||
| D | d | L | L | A | L | |
| DL2-35 | 14 | 8.5 | 37 | 111 | 22 | 60 |
| DL2-50 | 16 | 9.8 | 42 | 1120 | 22 | 60 |
| DL2-70 | 18 | 11.5 | 47 | 127 | 28 | 65 |
| DL2-95 | 20 | 13.5 | 50 | 135 | 28 | 65 |
| DL2-120 | 22 | 15 | 52 | 137 | 34 | 65 |
| DL2-150 | 25 | 16.5 | 55 | 143 | 34 | 65 |
| DL2-185 | 27 | 18.5 | 58 | 149 | 40 | 66 |
| DL2-240 | 30 | 21 | 60 | 153 | 40 | 66 |
| DL2-300 | 30 | 23 | 65 | 173 | 50 | 80 |
| DL2-400 | 34 | 26 | 65 | 180 | 50 | 80 |
| DL2-500 | 38 | 30 | 70 | 190 | 50 | 80 |
Terminal Value Of Packaging
Packaging Details:
packing can be supplied according customers request.
Shipping:
1. By Air or by Sea for batch goods,Airport/ Port receiving;
2. Customers specifying freight forwarders or negotiable shipping methods!
Delivery Detail:
Shipped in 7 days after payment
- Golden has been granted ISO9001 management system certifications. The comprehensive product line has more than 1000 models which have been approved by TUV,CE,CQC,SGS,ROHS,SASO. The productsells well to UK, Spain, Portugal, Singapore, Turkey, Russia, Korea, South Africa... more than 60 countries and regions.
- Golden is always striving hard to provide the best services and competitive price to all customers.
Recommend Products
1.Best ensure 100% customer satisfaction.
2.Our products have one year guarantee.
3.Sample in design and easy to operate and maintain.
4.All electrical parts of products are made up for qualitified marterials.
5.No MOQ limited for the trial order.
6.We adopt good credit quality electrial appliances.
7.Best customer care and effcient after-sale services.
8.Don't hesitate to inquire us,we will reply you within 12 hours.
Production and transport
Q1: Could I Put My Own Logo On It?
A1: Sure, of course, we are a professional manufacturer and have over 10 years OEM experience, customer;s logo can be made by laser, engraved, embossed, transfer printing etc.
Q2: What's the delivery time?
A2: Normally, 3-15days after order and payment confirmation. Actually, it will depend on your orderquality.
Q3: What's your terms of payment?
A3: T/T 30% as deposit, and 70% before delivery. We'll show you the photos of the products and packages before you pay the balance.
Q4: How do you make our business long-term and good relationship?
A4: a. We keep good quality and competitice price to ensure our customers benefit; b. We respect every customer as our friend and we sincerely do business and make friends with them, no matter where they come from.
Q5: If we bought your products, but found quality problem, how to solve?
A5: After confirmed, if the quality problem is caused by us not for outer sector, we will compensate each piece to customer.
