Metal IP68 EMC Cable Glands Brass Nickel Plated With High Temperature Resistance
Price:
Negotiable
MOQ:
1
Delivery Time:
Peak Season Lead Time: more than 12 months Off Season Lead Time: within 15 workdays
Brand:
Golden Electric /OEM
Product Description
What is the Special of Waterproof Cale Gland?
1.WIRE PROTECTION
Provides strain relief to cables and wires passing through plates or connecting to electrical equipment.
2.EASY INSTALLATION
Simply pass your cable through the gland and tighten the cap.
3.PROFESSIONAL LOOK
Black nylon cable glands are used by professionals everywhere.
4.VERSATILE
Used on all types of electrical, industrial, and automotive equipment and machinery
5.WATERPROOF
IP68 rating allows for underwater use. Resistant to salt water, weak acid, alcohol, oil, grease and common solvents.
![Standard Metal IP68 Electromagnetic EMC Brass Cable Glands]()
![Standard Metal IP68 Electromagnetic EMC Brass Cable Glands]()
![Standard Metal IP68 Electromagnetic EMC Brass Cable Glands]()
Field of Application
Packing&Delivery
packing can be supplied according customers request.
Delivery Detail:
Shipped in 7 days after payment
![Standard Metal IP68 Electromagnetic EMC Brass Cable Glands]()
![Standard Metal IP68 Electromagnetic EMC Brass Cable Glands]()
Related Products
![Standard Metal IP68 Electromagnetic EMC Brass Cable Glands]()
RFQ
Q1. What are your terms of packing?
A: Generally, we pack our goods in neutral white boxes and brown cartons. If you have legally registered a patent,
we can pack the goods in your branded boxes after getting your authorization letters.
Q2. What are your terms of payment?
A: T/T 30% as deposit, and 70% before delivery. We'll show you the photos of the products and packages
before you pay the balance.
Q3. What are your terms of delivery?
A: EXW, FOB.
Q4. How about your delivery time?
A: Generally, it will take 30 to 60 days after receiving your advance payment. The specific delivery time depends
on the items and the quantity of your order.
Q5. Can you produce according to the samples?
A: Yes, we can produce your samples or technical drawings. We can build the molds and fixtures.
Q6. What is your sample policy?
A: We can supply the sample if we have ready parts in stock, but the customers have to pay the sample cost and the courier cost.
1.WIRE PROTECTION
Provides strain relief to cables and wires passing through plates or connecting to electrical equipment.
2.EASY INSTALLATION
Simply pass your cable through the gland and tighten the cap.
3.PROFESSIONAL LOOK
Black nylon cable glands are used by professionals everywhere.
4.VERSATILE
Used on all types of electrical, industrial, and automotive equipment and machinery
5.WATERPROOF
IP68 rating allows for underwater use. Resistant to salt water, weak acid, alcohol, oil, grease and common solvents.
Cap nut: Brass with nickel Plated
Clamping Insert: PA66 ( Flammability UL 94V-2)
Gland Body: Brass with nickel plated
Certificate: CE, IP68, ISO9001, TUV
Protection Class : IP68-10 BAR
Operating Temperature: -40 DEG to +100 DEG, (short time to 120 DEG); -20 DEG to 80 DEG, (short time to 100 DEG)
Function: Metal Cable Gland is cable supporting products, connector cable can be locked, the other end of the device can access the device through the box body, also can choose thread access according to the entry and outlet of the internal thread electrical equipment.
Features: The claws and seals of excellent design, sealing nut have a "click" sound and re-open, can hold cable firmly and have a wider cable range. Resistant to salt water, weak acid, alcohol, oil, grease and common solvency.When shielded cable entries through this cable gland, the brass material contact chips attached in the cable gland will contact with the metal isolated network in the cable, Then the interfering electromagnetic wave will be leaded to the grounding wire, thus the interference source of electromagnetic wave will be evacuated.
Product parameters:
| EMC Cable Gland - G,NPT thread | |||||||
| Product Code | Thread AG | Cable range(mm) | Thread O.D.(mm) | Mounting Hole Diameter (mm) | Thread length GL(mm) | Spanner Size (mm) | Std, Pkg (pcs) |
| JX-E.G1/4A-EMC | G1/4'' | 3-5.3 | 13.157 | 13.2-13.4 | 8 | 17/17 | 10 |
| JX-E.G1/4B-EMC | 4.5-7.8 | 13.157 | 13.2-13.4 | 8 | 17/17 | 10 | |
| JX-E.G3/8A-EMC | G3/8'' | 4-7 | 16.662 | 16.7-16.9 | 9 | 22/22 | 10 |
| JX-E.G3/8B-EMC | 6-10 | 16.662 | 16.7-16.9 | 9 | 22/22 | 10 | |
| JX-E.G1/2A-EMC | G1/2'' | 7-11 | 20.955 | 21-21.2 | 9.5 | 26/26 | 10 |
| JX-E.G1/2B-EMC | 9-14 | 20.955 | 21-21.2 | 9.5 | 26/26 | 10 | |
| JX-E.G3/4A-EMC | G3/4'' | 12-16 | 26.411 | 26.5-26.8 | 12 | 32/32 | 10 |
| JX-E.G3/4B-EMC | 14-18 | 26.411 | 26.5-26.8 | 12 | 32/32 | 10 | |
| JX-E.G1A-EMC | G1'' | 16-22 | 33.249 | 33.3-33.6 | 12.5 | 41/41 | 10 |
| JX-E.G1B-EMC | 18-25 | 33.249 | 33.3-33.6 | 12.5 | 41/41 | 10 | |
| JX-E.G11/4A-EMC | G1 1/4'' | 21-25 | 41.91 | 42-42.3 | 15 | 50/50 | 5 |
| JX-E.G11/4B-EMC | 24-30 | 41.91 | 42-42.3 | 15 | 50/50 | 5 | |
| JX-E.G11/2A-EMC | G1 1/2'' | 26-32 | 47.803 | 48-48.4 | 15 | 60/60 | 2 |
| JX-E.G11/2B-EMC | 31-41 | 47.803 | 48-48.4 | 15 | 60/60 | 2 | |
| JX-E.G2A-EMC | G2'' | 40-46 | 59.614 | 60-60.4 | 15 | 73/73 | 2 |
| JX-E.G2B-EMC | 44-51 | 59.614 | 60-60.4 | 15 | 73/73 | 2 | |
| JX-E.G21/2A-EMC | G2 1/2'' | 50-56 | 75.184 | 75.2-75.6 | 18 | 85/88 | 1 |
| JX-E.G21/2B-EMC | 56-66 | 75.184 | 75.2-75.6 | 18 | 85/88 | 1 | |
| JX-E.NPT3/8A-EMC | NPT3/8'' | 4-7 | 17.055 | 17.1-17.3 | 13 | 22/22 | 10 |
| JX-E.NPT3/8B-EMC | 6-10 | 17.055 | 17.1-17.3 | 13 | 22/22 | 10 | |
| JX-E.NPT1/2A-EMC | NPT1/2'' | 7-11 | 21.223 | 21-21.2 | 13 | 26/26 | 10 |
| JX-E.NPT1/2B-EMC | 9-14 | 21.223 | 21-21.2 | 13 | 26/26 | 10 | |
| JX-E.NPT3/4A-EMC | NPT3/4'' | 12-16 | 26.568 | 26.5-26.8 | 14 | 32/32 | 10 |
| JX-E.NPT3/4B-EMC | 14-18 | 26.568 | 26.5-26.8 | 14 | 32/32 | 10 | |
| JX-E.NPT1A-EMC | NPT1'' | 16-22 | 33.227 | 33.3-33.6 | 15 | 41/41 | 10 |
| JX-E.NPT1B-EMC | 18-25 | 33.227 | 33.3-33.6 | 15 | 41/41 | 10 | |
| JX-E.NPT11/4A-EMC | NPT1 1/4'' | 21-25 | 41.984 | 42-42.3 | 15 | 50/50 | 5 |
| JX-E.NPT11/4B-EMC | 24-30 | 41.984 | 42-42.3 | 15 | 50/50 | 5 | |
| EMC Cable Gland E Series- PG thread | |||||||
| Product Code | Thread AG | Cable range(mm) | Thread O.D.(mm) | Mounting Hole Diameter (mm) | Thread length GL(mm) | Spanner Size (mm) | Std, Pkg (pcs) |
| JX-E.PG7A-EMC | PG7 | 3-5.3 | 12.5 | 12.5-12.8 | 8 | 17/17 | 10 |
| JX-E.PG7B-EMC | 4.5-7.8 | 12.5 | 12.5-12.8 | 8 | 17/17 | 10 | |
| JX-E.PG9A-EMC | PG9 | 3-5.8 | 15.2 | 15.2-15.5 | 8 | 18/17 | 10 |
| JX-E.PG9B-EMC | 4.5-7.8 | 15.2 | 15.2-15.5 | 8 | 18/17 | 10 | |
| JX-E.PG11A-EMC | PG11 | 4-7 | 18.6 | 18.6-18.9 | 9 | 22/22 | 10 |
| JX-E.PG11B-EMC | 6-10 | 18.6 | 18.6-18.9 | 9 | 22/22 | 10 | |
| JX-E.PG13.5A-EMC | PG13.5 | 5-8.8 | 20.4 | 20.4-20.7 | 9.5 | 24/24 | 10 |
| JX-E.PG13.5B-EMC | 7-12 | 20.4 | 20.4-20.7 | 9.5 | 24/24 | 10 | |
| JX-E.PG16A-EMC | PG16 | 7-11 | 22.5 | 22.5-22.8 | 9.5 | 26/26 | 10 |
| JX-E.PG16B-EMC | 9-14 | 22.5 | 22.5-22.8 | 9.5 | 26/26 | 10 | |
| JX-E.PG21A-EMC | PG21 | 12-16 | 28.3 | 28.3-28.7 | 12 | 32/32 | 10 |
| JX-E.PG21B-EMC | 14-18 | 28.3 | 28.3-28.7 | 12 | 32/32 | 10 | |
| JX-E.PG29A-EMC | PG29 | 16-22 | 37 | 37-37.4 | 12.5 | 41/41 | 10 |
| JX-E.PG29B-EMC | 18-25 | 37 | 37-37.4 | 12.5 | 41/41 | 10 | |
| JX-E.PG36A-EMC | PG36 | 21-25 | 47 | 47-47.4 | 15 | 50/50 | 5 |
| JX-E.PG36B-EMC | 24-30 | 47 | 47-47.4 | 15 | 50/50 | 5 | |
| Brass EMC Cable Gland E Series- Metric thread | |||||||
| Product Code | Thread AG | Cable range(mm) | Thread O.D.(mm) | Mounting Hole Diameter (mm) | Thread length GL(mm) | Spanner Size (mm) | Std, Pkg (pcs) |
| JX-E.M12A-EMC | M12*1.5 | 3-5.3 | 12 | 12-12.3 | 8 | 17/17 | 5 |
| JX-E.M12B-EMC | 4.5-7.8 | 12 | 12-12.3 | 8 | 17/17 | 10 | |
| JX-E.M16A-EMC | M16*1.5 | 4-7 | 16 | 16-16.3 | 9 | 22/22 | 10 |
| JX-E.M16B-EMC | 6-10 | 16 | 16-16.3 | 9 | 22/22 | 10 | |
| JX-E.M20A-EMC | M20*1.5 | 5-8.8 | 20 | 20-20.3 | 9.5 | 24/24 | 10 |
| JX-E.M20B-EMC | 7-12 | 20 | 20-20.3 | 9.5 | 24/24 | 10 | |
| JX-E.M20C-EMC | 9-14 | 20 | 20-20.3 | 9.5 | 26/26 | 10 | |
| JX-E.M25A-EMC | M25*1.5 | 12-16 | 25 | 25-25.4 | 12 | 32/32 | 10 |
| JX-E.M25B-EMC | 14-18 | 25 | 25-25.4 | 12 | 32/32 | 10 | |
| JX-E.M32A-EMC | M32*1.5 | 16-22 | 32 | 32-32.4 | 12.5 | 41/41 | 10 |
| JX-E.M32B-EMC | 18-25 | 32 | 32-32.4 | 12.5 | 41/41 | 10 | |
| JX-E.M40A-EMC | M40*1.5 | 21-25 | 40 | 40-40.4 | 15 | 50/50 | 10 |
| JX-E.M40B-EMC | 24-30 | 40 | 40-40.4 | 15 | 50/50 | 5 | |
| JX-E.M50A-EMC | M50*1.5 | 26-32 | 50 | 50-50.4 | 15 | 60/60 | 2 |
| JX-E.M50B-EMC | 31-41 | 50 | 50-50.4 | 15 | 60/60 | 2 | |
| JX-E.M63A-EMC | M63*1.5 | 40-46 | 63 | 63-63.4 | 15 | 73/73 | 2 |
| JX-E.M63B-EMC | 44-51 | 63 | 63-63.4 | 15 | 73/73 | 2 | |
| JX-E.M75A-EMC | M75*1.5 | 50-56 | 75 | 75-75.6 | 15 | 85/88 | 1 |
| JX-E.M75B-EMC | 56-66 | 75 | 75-75.6 | 15 | 85/88 | 1 | |
| JX-E.M90A-EMC | M90*1.5 | 58-68 | 90 | 90-91 | 20 | 102/106 | 1 |
| JX-E.M90B-EMC | 66-77 | 90 | 90-91 | 20 | 102/106 | 1 | |
| JX-E.M100A-EMC | M100*1.5 | 58-68 | 100 | 100-101 | 25 | 116/120 | 1 |
| X-E.M100B-EMC | 66-77 | 100 | 100-101 | 25 | 116/120 | 1 | |
Customization is acceptable.Welcome to inquire.
Field of Application
Cable glands are mechanical cable entry devices. They are used throughout a number of industries in conjunction with cable and wiring used in elelctrical instrumentation and automation systems.
Cable gland may be used on all types of electrical power, control, instrumentation, data and telecommunications cables. They are used as a sealing and termination device to ensure that the charachteristcs of the enclosure which the cable enters can be maintained adequately.
