10.1-inch LVDS Interface LCD Panel with 1280x800 Resolution and 400 Nits Brightness for Industrial Use
Price:
To Be Negotiated
MOQ:
38pcs
Delivery Time:
1~15 Working Days
Brand:
LB
Product Description
10.1-Inch IPS LCD Panel with Touchscreen for Option
The 10.1-inch LCD Panel is a high-performance display solution engineered for modern applications requiring vibrant visuals and exceptional image clarity. With a resolution of 1280×800 pixels, this panel delivers crisp, detailed images ideal for industrial equipment, consumer electronics, and professional applications.
Advanced Display Technology
Utilizing advanced Thin Film Transistor (TFT) technology, this display provides fast response times and high contrast ratios, ensuring smooth transitions and vibrant image quality without blurring or ghosting effects.
IPS Panel Benefits
The In-Plane Switching (IPS) panel technology offers wide viewing angles of 85/85/85/85 degrees with consistent color performance. This minimizes color shifting and brightness loss when viewed from different angles, making it perfect for collaborative environments and public display settings.
Touchscreen Capability
An optional touchscreen feature transforms this display into an interactive interface, enabling intuitive control through touch gestures. This enhancement is particularly valuable for kiosks, handheld devices, and point-of-sale systems.
Product Features
- Product Name: Liquid Crystal Display Panel (LCD Panel)
- Resolution: 1280×800 pixels
- Display Type: IPS Display Panel
- Backlight Type: LED-backlit LCD Panel
- Viewing Angle: 85/85/85/85 Degrees
- Quantity per Carton: 38 pcs
- Storage Temperature Range: -20°C to 70°C
Technical Specifications
| Parameter | Specification |
|---|---|
| Interface | LVDS, 1 Ch, 8-bit, 40 Pins |
| Display Area | 597.6(H) × 336.15(V) mm |
| Panel Type | IPS (Thin Film Transistor Display) |
| Lamp Type | WLED, 30K Hours, With LED Driver |
| Storage Temperature | -20°C to 70°C |
| Pixel Format | RGB Vertical Stripe |
| Display Mode | Normally Black |
| Frequency | 60Hz |
| Display Colors | 16.7 Million |
| Luminance | 400 cd/m² |
Applications
The LB101LVDS09 LED-backlit LCD Panel is designed for diverse industrial and commercial applications including:
- Commercial signage and digital displays
- Industrial control systems and monitoring
- Medical devices and equipment
- Kiosks and point-of-sale (POS) terminals
- Educational tools and interactive displays
- Digital dashboards and multimedia applications
Model LB101LVDS09: RoHS compliant, made in China. Supply capacity of 1000pcs per day with minimum order quantity of 38pcs. Delivery within 1-15 working days with flexible payment terms.
