30T-60T Mechanical Suspension Self Discharge Dumping Truck Semi Trailer To Carry Gravels
Product Description:
Self-tipping mechanism, making loading and unloading quick and easy. The side tipper semi trailer design allows for efficient unloading, even in tight spaces.
With its sturdy design, high loading capacity, and efficient unloading capabilities, it's the perfect choice for transporting bulk goods.
Features:
1.equipped to handle your sand, gravels, clinkers and small aggregate needs, and tipping easily2.equipped with an open-box bed, which is hinged at the rear and equipped with hydraulic rams to lift the front
3.available in many configurations, type and dimensions
Technical Parameters:
| overall dimension (LxWxH) | 11280×2490×3970 mm |
| box dimension (LxWxH) | 10500×2320×1500 mm |
| Tare Weight | 8.5T-10T |
| Payload | 40T-100T(35 m³-40m³) |
| Axle Weight Load | 13T/14T/16T/20T per axle |
| Axle number | 3 |
| Axle specs | FUWA,JINSHENG/BPW brand |
| Suspension | mechanical suspensions |
| King Pin | 50#/90# traction pin |
| Lifting system | Full set of Hyva hydraulic system/ Full set of Jiuzhouzhongli hydraulic system |
| Steel Spring | 10pieces |
| Landing Gear | 28 ton capacity |
| Tire specs. | 12.00R20-18 |
| Frame (specs. and materials) | Main frame is height 500mm |
| Frame Beam | Upper and lower plate is 20mm, middle is10mm(Double+three plate). height is 500 mm |
| Frame Floor | The Thickness is 3mm flat bed |
| Brake System | Dual line braking system |
| Brake Chamber | Two double chamber/ABS |
| Brake valve | WABCO |
| Electrical System | 1.Voltage: 24v 2. Receptacle: 7 ways (7 wire harness) |
| Lamp | LED |
| Color | Any color will be available |
| Accessory | One tooling box with a set of standard trailer tool |
Applications:
The Dump/Tipping Semi Trailer is a type of semi-trailer that is used for transporting heavy loads and dumping them at the desired location.
The Dump/Tipping Semi Trailer can be used in a variety of applications and scenarios. It is commonly used in the construction industry for transporting building materials such as sand, gravel, and concrete. The rear dumping semi-trailer is also used in the mining industry for transporting coal and other minerals. The side tipper semi-trailer is used for transporting goods that need to be unloaded quickly and efficiently.
FAQ:
Q: What is the brand of this dump/tipping semi trailer?
A: The brand name of this product is AOTONG.
Q: Where is this dump/tipping semi trailer manufactured?
A: This product is manufactured in China.
Q: Does this dump/tipping semi trailer have any certifications?
A: Yes, this product has ISO and CCC certifications.
Q: What is the minimum order quantity for this dump/tipping semi trailer?
A: The minimum order quantity for this product is 1 unit.
Q: How long is the delivery time for this dump/tipping semi trailer?
A: The delivery time for this product is 25 days.
Q: What are the payment terms for this dump/tipping semi trailer?
A: The payment terms for this product are TT
