3 Axles Animal Or Cargo Transport Fence Type Truck Trailers
Usage:
Suitable for the agricultural, sideline products and other light products' transportation. The design is convenient for products' unloading, and it's not only satisfy the rated load also reduce the burden of the compartments.
Descriptions:
The cargo's carring part of the stake truck is store house bar style designed, the beam wears through the longitudinal beam which is welded as a space frame structure, making the frame strength, stiffness, flexibility an equilibrium, a strong carrying capacity without permanent deformation.
Specifications:
| Size | 12500*2500*(3000-4500) (mm) |
| Payload | 50000KG |
| Main beam | Heavy duty I beam. |
| Cross beam | 160mm |
| Floor | 1-4 floor optional |
| Axles | 3 * 13ton capacity (Brand optional) |
| Suspension | Mechanical suspension (Air suspension optional) |
| Leaf spring | 10pcs |
| Tire | 12R22.5 12pcs (Other size optional) |
| Rim | 9.00-22.5 12pcs (Other size optional) |
| Kin pin | 2’’/3.5’’ bolt type |
| Landing gear | 28 Ton two speed |
| Twist locks | optional |
| Braking system | Double air chamber ,brake valve,40L air tanks ;ABS optional |
| Electrical | LED light , 7 ways ,24V |
| Painting | Blasting and clean rust,1 coat of prime painting ,2 coat of finish painting |
Top Manufacturers for good quality semi trailers.
1.More than 30 years manufacturing experiences provide qualified truck trailers & competitive price.
2.Experienced Design & QC team, strict quality control.CCC,ISO,SGS,BV agree
3.Customized a variety of semi trailer required by customers. Well designed ,small order accept.
4.Manufacture according to your detailed requirements
5.After-sale-support,6 month guarantee term
