20ft 40ft 45ft Steel Container Chassis Semi Trailer with Mechanical Air Suspension
| Main specification of 2 axles container skeleton semi trailer | |
| Model | 20ft skeleton semi trailer |
| Overall dimensions | 7500x2500x1550 mm |
| Loading weight | 40,000 kg |
| Tare weight | 6.350 kg |
| Container twist lock | 12 pcs |
| Main beam |
Q345B carbon steel The height of the beam is 500mm, upper plate is 14mm, down plate is 16mm, middle plate is 8mm |
| Side beam | Q235 16mm channel steel |
| Platform thickness | 3 mm diamond plate |
| Axle brand | 13 ton FUWA Brand axle |
| Axle number | 2 |
| Landing gear | Standard 28 ton |
| Suspension system | Mechanical leaf spring suspension |
| Steel spring | 10/10 90mm(width)*13mm(thickness)*10 layers |
| Kingpin | 50mm or 90mm |
| Tire | 12R22.5 tubeless tire |
| Tire quantity | 8 |
| Brake system | Dual line braking system, no ABS |
| Brake chamber | 6 double chamber |
| Light | Tail lamp with turn signal, brake light & reflector, side lamp, etc |
| Painting |
Complet chassis sand blasting to clean rust, one coat anti-rust prime, two coats final paint, color as customer's requirement |
Yes, we have our own factory in Shandong, China, specializing in trailer manufacturing for several years. Our facility is well-known for producing various types of trailers.
One unit.
Absolutely! We can customize trailers according to your specific requirements.
We provide multiple transportation options:
- Primary method: Shipping by container or ro-ro/bulk vessel
- For neighboring countries: Road or rail transport
- For urgent spare parts: Express shipping via DHL, TNT, UPS or FEDEX
Our comprehensive services include competitive pricing, shipping and packaging solutions, cargo hold booking assistance, and parts procurement support.
Send your inquiry to begin our partnership. Our expert team is ready to assist you throughout the process.
With over 30 years of trailer manufacturing experience, we've earned your trust through quality and reliability.
