Stainless Steel Output Part HS700 Vacuum Pressure Calibration Pump 0.01mbar Resolution

HS700 Vacuum pressure calibration pump  Technical Specification
1. Generated pressure range:(-0.5~0.5)kPa
2. Working media:Air
3. Adjust resolution:1Pa(0.01mbar)

4. Output interface connection:  M20×1.5Female
    Differential port for connect gauges under test by hose
5. Weight:2.55kg

HS700 Vacuum pressure calibration pump  is made from high quality and transparent plexiglass material.The operation of piston inside can be seen clearly . The whole structure is more intuitive and compact.This instrument is specially designed to generate micro pressure from vacuum to 50kPa. The F-adjust valve could accomplish 1Pa (0.01mbar) pressure resolution. HS700 is a very stable Mirco Pressure Calibrator. the design of relieve valve makes the system return to zero pressure quickly.two standard pressure outputs are easy to connect gauges under test without using the wrenches. the differential port also may connect gauges under test by hose. It widely calibrates micro pressure instruments in field and laboratory.

 HS700 Vacuum pressure calibration pump Functions
HS700 provides pressure measurement for calibrating micro pressure instruments in field and laboratory . It can be extensively used in power, chemical, petrol, metallurgy, metering, military industry, etc.

  HS700 Vacuum pressure calibration pump  Characteristics
1. Adopts high quality and transparent plexiglass material.
2. The whole structure is more intuitive and compact.
3. Simple operation, convenient maintenance.
4. Pressure resolution:1Pa(0.01mbar)
