P20 Pixel Pitch IP65 Waterproof 12000 Brightness VMS LED Sign for Highway Roadway Safety
Price:
$115-135
MOQ:
1
Delivery Time:
Negotiable
Brand:
Glare-LED
Product Description
P20 Full Color Traffic VMS LED Sign Message Board for Highway Roadway Safety
Glare-LED variable message signs and traffic guidance equipment provide traffic information dissemination through LED lighting devices. These display units effectively show basic traffic information with graphics and text. Operators can release various notices and information based on instructions from traffic, weather, and dispatching departments, effectively guiding traffic flow, improving road network capacity, and enhancing driver safety.
Product Features
- Versatile and interchangeable display modules can be configured in different colors and sizes
- Double-box structure creates natural convection for temperature equilibrium
- Pixel module junction box with "O" ring provides excellent moisture resistance
- Advanced soft silicone module packaging with elasticity and strong anti-aging properties
- Heat sink cooling for power supply and IC devices ensures stable performance
- Special wide temperature range components guarantee operation in extreme conditions
- High-speed serial transmission network reduces complexity and improves stability
- Network cable data transmission enhances display stability and response speed
- Common network data transmission technology improves gradation display and compatibility
Product Waterproof Cabinet Design
Cabinet Color Options
Product Specifications
| Lamp beads | Specific traffic lighting LEDs |
| Pixel pitch | P16, P20, P25, P31.25, P33.33 |
| Display dimension | Customizable |
| Cabinet material | Aluminum or cold rolled iron |
| Chip color | Amber, tri-color, full color or custom |
| Brightness | >10000cd/m² |
| Brightness adjustment | Manual or auto adjust |
| Viewing distance | 250-300m |
| Control mode | Asynchronous control |
| Communication port | RS232/RS485/RJ45/GPRS/3G etc |
| Refresh rate | >120Hz |
| Certificates | CE/FCC/ROHS etc |
| Life span | 100,000 hours |
| Rate of dot out of control | <1/10000 |
| Insulation resistance | >100MΩ |
| High voltage resistance test | Withstand 1500V / 50Hz AC voltage for 1 minute without breakdown |
| Impact resistance test | Pass |
| Vibration resistance test | Pass |
| Contact resistance | <0.1Ω |
| Protection class | IP65 |
| Operating Humidity | 5%-95% |
| Operating temperature | -40ºC to +75ºC |
| Power supply | AC220V±18% / 50Hz±10% or AC380V±18% / 50Hz±10% |
Product Configuration and Standards
| Name | Specification | Function |
|---|---|---|
| Control system | Main control system | Communicate with the center of the screen drive traffic monitoring |
| Brightness adjust system | Brightness adjustment based on ambient light | Traffic control system screen brightness |
| Power system | Power distributor | Centralized power system distribution box |
| Power lightning protection devices | Imported professional lightning protection | Signal lightning protection devices |
| Remote Switch electrical system | Remote Switch electrical system | With remote, step-switch function |
| Communication module | RS-485 communication module | Industrial grade communication module |
| RS-232 communication module | Ethernet communication module |
LED Variable Message Signs Compliance Standards
| LED variable message screen | GB/T 23828-2009 | Fully in accordance with international design, production and testing |
| Traffic sign display | GB 5768.2 | Traffic sign text, graphics meet the standards |
| Chinese character display | GB 2312 | Digital display standard Chinese characters |
| Shell protection grade | GB 7000.1 | IP65 protection rating |
| Communication interfaces and protocols | JT/T606.1 and JT/T606.3 | Standard asynchronous |
Quality Control Process
Package Method
Company Profile
Project Case
Frequently Asked Questions
What do the gas price display come with?
Pixel tube cluster signs the control card power supply are inside the cabinets. No need control box anymore.
What is the warranty policy should the LED price billboards arrive damaged?
We are pleased to offer our convenient warranty policy.
How long do gas price signs last?
Our signs can last an average of 6 years.
Can you provide finished product solution for exhibition or bid?
Yes, we can. We have 10 years experience in this trade with nearly 30 R&D departments.
Can you provide the digital board as the size of customing?
Yes, of course. We offer many standard sizes, but can also accommodate custom sizes. Please contact our LED Gas Signs Customers team for details.
