China 32200 Series Taper Roller Bearing Distributor Separated for Radial Load Direction for sale

32200 Series Taper Roller Bearing Distributor Separated for Radial Load Direction

Name: 32200 Series Taper Roller Bearing Distributor Separated for Radial Load Direction
Brand: Cixi Super International Trade Co., Ltd.

Price Negotiable

Price: Negotiable

MOQ: 1000PCS

Delivery Time: Peak Season Lead Time: one month, Off Season Lead Time: within 15 workdays

Product Description

HEAVY DUTY NEEDLE ROLLER BEARINGS WITH INNER RING
NKI NKIS NA49, NA69 series.
Heavy duty needle roller bearings without inner ring
NK NKS RNA4, RNA6 series.

32200 Series Taper Roller Bearing Rolling Bearing Distributor

30200 series
Model	d mm	D mm	H mm	W kg
30202	15	35	12	0.043
30203	17	40	13.5	0.053
30204	20	47	15.5	0.126
30205	25	52	16.5	0.154
30206	30	62	17.5	0.231
30207	35	72	17	0.331
30208	40	80	20	0.422
30209	45	85	21	0.474
30210	50	90	22	0.529
30211	55	100	23	0.713
30212	60	110	24	0.904
30213	65	120	25	1.13
30214	70	125	26.5	1.26
30215	75	130	27.5	1.32
30216	80	140	28.5	1.67
30217	85	150	31	2.06
30218	90	160	33	2.54
30219	95	170	35	3.04
30220	100	180	37.5	3.72
32324	120	260	91	21.8

30300 series
Model	d mm	D mm	H mm	W kg
30302	15	42	14.5	0.093
30303	17	47	15.5	0.13
30304	20	52	16.5	0.165
30305	25	62	18.5	0.263
30306	30	72	21	0.387
30307	35	80	23	0.515
30308	40	90	25.5	0.747
30309	45	100	27.5	0.984
30310	50	110	29.5	1.28
30311	55	120	32	1.63
30312	60	130	34	1.99
30313	65	140	36.5	2.44
30314	70	150	38.5	2.98
30315	75	160	40.5	3.57
30316	80	170	43	4.27
30317	85	180	45	4.95
30318	90	190	47	5.8
30319	95	200	50	6.8
30320	100	215	52	8.22
32326	130	280	99.5	26.6

32200 series
Model	d mm	D mm	H mm	W kg
32204	20	47	19.25	0.151
32205	25	52	19.2	0.174
32206	30	62	21.5	0.273
32207	35	72	24.5	0.426
32208	40	80	25	0.576
32209	45	85	25	0.587
32210	50	90	25	0.612
32211	55	100	27	0.881
32212	60	110	30	1.91
32213	65	120	33	1.57
32214	70	125	33.5	1.58
32215	75	130	33.5	1.74
32216	80	140	35.5	2.15
32217	85	150	39	2.75
32218	90	160	43	3.42
32219	95	170	46	4.33
32220	100	180	49.5	5.14
32221	105	190	53	5.9
32322	110	240	85	18.1
32330	150	320	115	37.1

32300 series
Model	d mm	D mm	H mm	W kg
32303	17	47	20.5	0.171
32304	20	52	22.5	0.256
32305	25	62	25.5	0.366
32306	30	72	29	0.574
32307	35	80	33	0.804
32308	40	90	35.5	1.03
32309	40	100	38.5	1.4
32310	50	110	42.5	1.83
32311	55	120	46	2.34
32312	60	130	40	2.81
32313	65	140	51.5	3.75
32314	70	150	54.5	3.96
32315	75	160	58.5	5.64
32316	80	170	62	6.78
32317	85	180	64	7.33
32318	90	190	68	8.91
32319	95	200	72	10.5
32320	100	215	78	12.8
32321	105	225	82	13.8
32334	170	360	127	58.3
