670mm Cross Travel Y-axis Metal Bed Type Milling Machine BM715 for Industry Production
Price:
$47,000.00/sets >=1 sets
MOQ:
1 set
Delivery Time:
Negotiable
Brand:
Timac
Product Description
One-Stop Shopping
You can click on the picture to view the products you are interested in
Products Description
bed type milling machine
Features:
* Servo feed motors on X, Y, Z-axis ensures response,accuracy and consistent feed;
* Micro switch on the manual knee handle for additional operator safety;
* Tool box and operations manual;
* Ball screw X, Y-axis providing smooth and accurate operation;
* Coolant system and halogen light included;
* Square construction slides for X, Z-axis to maximize rigidity;
* Clutch hand wheels X, Y-axis;
* Automatic oil lubrication pump and reservoir;
* Universal head swivels to horizontal position;
* Servo feed motors on X, Y, Z-axis ensures response,accuracy and consistent feed;
* Micro switch on the manual knee handle for additional operator safety;
* Tool box and operations manual;
* Ball screw X, Y-axis providing smooth and accurate operation;
* Coolant system and halogen light included;
* Square construction slides for X, Z-axis to maximize rigidity;
* Clutch hand wheels X, Y-axis;
* Automatic oil lubrication pump and reservoir;
* Universal head swivels to horizontal position;
Specification | Unit | BM715 |
Table size | mm | 2100 x 500 |
Spindle taper | - | ISO50 |
Longitudinal travel (X-axis) | mm | 1500 |
Cross travel (Y-axis) | mm | 670mm |
Vertical travel (Z-axis) | mm | 670mm |
T-slot number/width/distance | mm | 4/20/100 |
Type of slides | - | Square (Y & Z) |
Distance from spindle axis to column guideway | mm | 610mm |
Type of table power feed (X , Y & Z-axis) | - | Servo Drive |
Longitudinal & Cross feed (X & Y-axis) | mm/min | 20 ~ 1800 |
Longitudinal & Cross rapid (X & Y-axis) | mm/min | 3500 |
Vertical feed (Z-axis) | mm/min | 10 ~ 900 |
Vertical rapid (Z-axis) | mm/min | 1750 |
Work table load capacity | kg | 2000 |
Spindle speeds vertical / horizontal | r.p.m | 12steps (35-1345) |
Motor power | kw | 7.5(10HP) |
Floor space required | mm | 4925 x 2380 |
Overall dimension | mm | 3300 x 2380 x 2750 |
N.W / G.W | kg | 7300 / 8000 |
Standard accessories
Draw bar Tool box
Oil gun 7:24 Middle sleeve
Inner hexagon Spanner ISO50 milling Chuck
Double-end wrench ISO50 milling arbor
Horizontal milling arbor Operation manual
Horizontal milling arbor supporting Operation manual
Foundation bolts
Oil gun 7:24 Middle sleeve
Inner hexagon Spanner ISO50 milling Chuck
Double-end wrench ISO50 milling arbor
Horizontal milling arbor Operation manual
Horizontal milling arbor supporting Operation manual
Foundation bolts
Why Choose Us
Our Services
1. Free replacing parts available in the warranty period. Cost price replacing parts available beyond the warranty period. 2. Quick action and reply for the technical questions at any time in the whole life of the machine. 3. Overseas after service center available in some region. 4. Engineer overseas service available on the requirement of customer(relative cost born by customer).
FAQ
Q: Why choose TIMEWAY MACHINE?
A: 1 . High quality with competitive price; 2 . Professional R&D team and 25 years export experience; 3 . Exported more than 60 countries; 4 . CE, ISO Certificates; 5 . 24 HOURS ONLINE SERVICE (SKYPE, WhatsApp, Wechat, Trademanager); 6 . 12 months quality warranty; 7 . Oversea engineers available for problem resolving; Q: Do you have QC or any safety standards for your machinery? A: yes, we have established a highly strict quality control department to guanrantee good quality. Q: What's the MOQ? A: 1 set (Only some low cost machines will be more than 1 set ) Q: What about the payment terms? A: (1) T/T with 30% advanced payment, and 70% balance payment to be paid before shipment; (2) Irrevocable LC at sight; (3) Western Union, MoneyGram, etc. Q: How about the warranty? A: Warranty Period is one year after delivery. Even beyond the period, we will supply lifetime service for machine.
