AL 2000 Lathe Machine for Industrial Manufacturing Max. Turned Length mm 2800 mm
Price:
$73,000.00/sets 1-2 sets
MOQ:
1 set
Delivery Time:
Negotiable
Brand:
Timeway
Product Description
Products Description
Specification | Unit | AL-1800 | AL-2000 | |
Max. swing over bed | mm | 1800 | 2000 | |
Max. swing over cross slide | mm | 1450 | 1650 | |
Distance between centers | mm | 3000/4000/5000/6000/8000/10000/12000 | ||
Max. turning length | mm | 2800/3800/4800/5800/7800/9800/11800 | ||
Bed width | mm | 1100 | 1100 | |
Loading capacity | tons | 16 | 16 | |
Spindle nose | - | A2-15 | A2-15 | |
Spindle bore | mm | 100 | 100 | |
Spindle taper | - | Metric 140 | Metric 140 | |
Spindle speed range | r/min | CCW: 3.15-315, CW: 3.5-291 | CCW: 3.15-315, CW: 3.5-291 | |
Spindle speed step | steps | CCW: 21, CW: 12 | CCW: 21, CW: 12 | |
X/Z-axis feed kinds | kinds | 56 | 56 | |
Feed range | mm/r | Longitudinal:0.1-12; Cross:0.05-6; Top tool-post: 0.025-3 | ||
Metric threads range (kinds) | mm | 1-120 (44) | 1-120 (44) | |
Inch threads range (kinds) | TPI | 28-1/4 (31) | 28-1/4 (31) | |
Module threads range (kinds) | MP | 0.5-60 (45) | 0.5-60 (45) | |
Diametrical threads range (kinds) | DP | 1/2-56 (38) | 1/2-56 (38) | |
Distance from spindle center to tool base | mm | 53 | 53 | |
Tool post swivel angle | ° | ±90° | ±90° | |
Cross slide travel | mm | 900 | 900 | |
Top slide travel | mm | 360 | 360 | |
Tool section size | mm | 50x50 | 50x50 | |
Tool post feed per gar | mm | 0.05 | 0.05 | |
Tailstock quill diameter | mm | 260 | 260 | |
Tailstock quill travel | mm | 300 | 300 | |
Tailstock quill taper | - | Metric 80 | Metric 80 | |
Main motor power | kw | 30 | 30 | |
Machine length | mm | 6120/7120/8120/9120/11120/13120/15120 | ||
Machine width | mm | 2330 | 2430 | |
Machine height | mm | 2480 | 2580 | |
· 4-jaw heavy duty independent chuck · Steady rest · Dead center · 4-station tool post · Cooling system · Work lamp · Electric movingtailstock · Tools & tool-box · Leveling wedge and bolts · Operation manual (English) | · Face plate · 2 or 3-axis DRO · Chuck guard · Tool-post guard · Rear splash guard · Roller support · Grinding attachment |
Why Choose Us
Q: Why choose TIMEWAY MACHINE?
A: 1 . High quality with competitive price;
2 . Professional R&D team and 25 years export experience;
3 . Exported more than 60 countries;
4 . CE, ISO Certificates;
5 . 24 HOURS ONLINE SERVICE (SKYPE, WhatsApp, Wechat, Trademanager);
6 . 12 months quality warranty;
7 . Oversea engineers available for problem resolving;
Q: Do you have QC or any safety standards for your machinery?
A: yes, we have established a highly strict quality control department to guanrantee good quality.
Q: What's the MOQ?
A: 1 set (Only some low cost machines will be more than 1 set )
Q: What about the payment terms?
A: (1) T/T with 30% advanced payment, and 70% balance payment to be paid before shipment;
(2) Irrevocable LC at sight;
(3) Western Union, MoneyGram, etc.
Q: How about the warranty?
A: Warranty Period is one year after delivery. Even beyond the period, we will supply lifetime service for machine.
A: 1 . High quality with competitive price;
2 . Professional R&D team and 25 years export experience;
3 . Exported more than 60 countries;
4 . CE, ISO Certificates;
5 . 24 HOURS ONLINE SERVICE (SKYPE, WhatsApp, Wechat, Trademanager);
6 . 12 months quality warranty;
7 . Oversea engineers available for problem resolving;
Q: Do you have QC or any safety standards for your machinery?
A: yes, we have established a highly strict quality control department to guanrantee good quality.
Q: What's the MOQ?
A: 1 set (Only some low cost machines will be more than 1 set )
Q: What about the payment terms?
A: (1) T/T with 30% advanced payment, and 70% balance payment to be paid before shipment;
(2) Irrevocable LC at sight;
(3) Western Union, MoneyGram, etc.
Q: How about the warranty?
A: Warranty Period is one year after delivery. Even beyond the period, we will supply lifetime service for machine.
