10kw Hydraulic Rock Drill for Mechanized Bolting Hole Drilling in Underground Engineering
Price:
Negotiable
MOQ:
5
Delivery Time:
Peak Season Lead Time: one month, Off Season Lead Time: within 15 workdays
Product Description
HM10B/D rock drill
Product Description
The HM10B/D Hydraulic Rock Drill, with an impact power of 10 kW, is a hydraulic rock drill designed and developed for mechanized bolting hole drilling in underground engineering, non-coal mining, and coal mining construction projects.
Applications:
In coal mines, non-coal mines, and underground engineering, it can be used for bolting support to maintain tunnel safety.
In coal mining operations, it is suitable for drilling up to 55 mm in diameter.
Key Specifications:
Dimensions: 800*226*200mm
Weight: 103 kg
Impact Frequency: 47-53 Hz
Impact Power: 10 kW
Drilling Diameter: 32-64 mm
Shank Types: R32/T38/R38
Flow Rate: 62-68 L/min
Characteristics:
Low power, high impact
Compared to Epiroc and Sandvik models of the same power level, this rock drill is shorter
Most models can be assembled in both forward and reverse configurations, making them suitable for multi-boom drill rigs
![10kw Hydraulic Rock Drill for Mechanized Bolting Hole Drilling in Underground Engineering, Non-Coal Mining, and Coal Mining Construction]()
![10kw Hydraulic Rock Drill for Mechanized Bolting Hole Drilling in Underground Engineering, Non-Coal Mining, and Coal Mining Construction]()
![10kw Hydraulic Rock Drill for Mechanized Bolting Hole Drilling in Underground Engineering, Non-Coal Mining, and Coal Mining Construction]()
![10kw Hydraulic Rock Drill for Mechanized Bolting Hole Drilling in Underground Engineering, Non-Coal Mining, and Coal Mining Construction]()
![10kw Hydraulic Rock Drill for Mechanized Bolting Hole Drilling in Underground Engineering, Non-Coal Mining, and Coal Mining Construction]()
![10kw Hydraulic Rock Drill for Mechanized Bolting Hole Drilling in Underground Engineering, Non-Coal Mining, and Coal Mining Construction]()
![10kw Hydraulic Rock Drill for Mechanized Bolting Hole Drilling in Underground Engineering, Non-Coal Mining, and Coal Mining Construction]()
![10kw Hydraulic Rock Drill for Mechanized Bolting Hole Drilling in Underground Engineering, Non-Coal Mining, and Coal Mining Construction]()
Product Description
The HM10B/D Hydraulic Rock Drill, with an impact power of 10 kW, is a hydraulic rock drill designed and developed for mechanized bolting hole drilling in underground engineering, non-coal mining, and coal mining construction projects.
Applications:
In coal mines, non-coal mines, and underground engineering, it can be used for bolting support to maintain tunnel safety.
In coal mining operations, it is suitable for drilling up to 55 mm in diameter.
Key Specifications:
Dimensions: 800*226*200mm
Weight: 103 kg
Impact Frequency: 47-53 Hz
Impact Power: 10 kW
Drilling Diameter: 32-64 mm
Shank Types: R32/T38/R38
Flow Rate: 62-68 L/min
Product Details
Widely used in underground engineering, non-coal mining, and coal mining construction projects, the HM10B/D Rock Drill is commonly mounted on bolting and tunneling drill rigs. It features an internal damping oil circuit, which is simple, compact, easy to maintain, and cost-effective.Characteristics:
Low power, high impact
Compared to Epiroc and Sandvik models of the same power level, this rock drill is shorter
Most models can be assembled in both forward and reverse configurations, making them suitable for multi-boom drill rigs
![10kw Hydraulic Rock Drill for Mechanized Bolting Hole Drilling in Underground Engineering, Non-Coal Mining, and Coal Mining Construction]()
Technical Parameters
| HM10B/D (YYG-10/480) Rock Drill | ||
| Structure | ||
| Dimension (include shank) | mm*mm*mm | 785X226X200 |
| Weight | KG | 105 |
| Center Height | mm | 114 |
| Shank | - | R32/T38/R38 |
| Hole Diameter | mm | Φ32-64 |
| Impact Functions | ||
| Max. Impact Power | KW | 10 |
| Oil Inlet Pressure | Bar | 160 |
| Impact Frequency | HZ | 47-53 |
| Flow | L/min | 62-68 |
| Impact Energy | J | 135-160 |
| Rotation Functions | ||
| Displacement | CC | 100/125/160 |
| Rotation Speed | Rpm | 300 |
| Max. Torque | Nm | 480 |
| Oil Inlet Pressure | Bar | 175 |
| Flow | L/min | 48 |
| Others | ||
| Water Pressure | Bar | 10-15 |
| Water Flow | L/min | 30-60 |
| Air Lubrication Pressure | Bar | 3 |
| Lubrication Air Flow | L/S | 5 |
