Optimize Your Equipment's Performance with HFS211 Planetary Steering Axle Replacement
Price:
Negotiable
MOQ:
5
Delivery Time:
Peak Season Lead Time: one month, Off Season Lead Time: within 15 workdays
Product Description
Elite, committed to building a world-class drivetrain brand, strives to become a well-known manufacturer of planetary gearboxes, transfer cases and axles. With more than 20 years of experience in transmission design and manufacturing, Elite will provide you with customized gearboxes, transfer cases and axle solutions for any specific application.
Advantages
Drawing
![Planetary Steering Axle with High Performance Replacing of Dana Spicer 211/212]()
Parameter
![Planetary Steering Axle with High Performance Replacing of Dana Spicer 211/212]()
![Planetary Steering Axle with High Performance Replacing of Dana Spicer 211/212]()
![Planetary Steering Axle with High Performance Replacing of Dana Spicer 211/212]()
![Planetary Steering Axle with High Performance Replacing of Dana Spicer 211/212]()
![Planetary Steering Axle with High Performance Replacing of Dana Spicer 211/212]()
![Planetary Steering Axle with High Performance Replacing of Dana Spicer 211/212]()
Advantages
| 1 | It adopts a fully enclosed wet multi-disc braking,with hydraulic system for releasing and spring for braking, ensuring reliable braking and a long service life for the brake |
| 2 | Equipped with differential, it allows automatic speed differentiation between two wheels during turning,with smooth vehicle steering |
| 3 | The brake system includes a dedicated pressure oil cooling circuit, offering significant cooling effects and minimal wear on friction plates, suitable for frequent braking environments |
| 4 | lts advanced structural design and reliable quality make it widely applicable in mining machinery and construction machinery, especially suitable for narrow, low, and muddy working surfaces |
| 5 | Our axle parts are completely interchangeable with the American Dana axle211 parts. |
Drawing
Parameter
| Parameter | Unit | Value |
| Maximum brake pressure | Mpa | 8 |
| Maximun steering pressure | Mpa | 18.5 |
| Speed ratio of main reducer | I | 29:9 |
| Speed ratio of wheel reducer | I | 4.235:1 |
| Total speed ratio | I | 13.646 |
| Maximum static bearing capacity | N | 100000 |
| Maximum dynamic bearing capacity | N | 60000 |
