Durable Speed Changing Ground Tooth Planetary Gearbox with Service Brakes 180000nm
Price:
Negotiable
MOQ:
5
Delivery Time:
Peak Season Lead Time: one month, Off Season Lead Time: within 15 workdays
Product Description
Elite GFT Travel Drives are unsurpassed by any crawler or milling machines. Thanks to compact, rugged design, high torque and load capabilities, and optional mechanical lifetime seals, these solutions are the best possible option for the machine. All units are available with a fail-safe parking brake and most have the option of cartridge type fixed or variable systems.
Features:
Compact structure and space-saving design
Robust main bearing system
High torque capacity
High load capacity
Integrated static multiple disk parking brake
Optional Disconnect device for towing
Optional Quick disconnection device
Simple mounting
Easy oil change
Low-noise running operation
Specifications:
![Track Drives 180000nm Planetary Gearbox with Service Brakes]()
![Track Drives 180000nm Planetary Gearbox with Service Brakes]()
![Track Drives 180000nm Planetary Gearbox with Service Brakes]()
![Track Drives 180000nm Planetary Gearbox with Service Brakes]()
![Track Drives 180000nm Planetary Gearbox with Service Brakes]()
![Track Drives 180000nm Planetary Gearbox with Service Brakes]()
![Track Drives 180000nm Planetary Gearbox with Service Brakes]()
![Track Drives 180000nm Planetary Gearbox with Service Brakes]()
![Track Drives 180000nm Planetary Gearbox with Service Brakes]()
In conclusion, ELITE Hydraulic offers quality, value, and professional power transmission solutions that cater to a wide variety of industries. With their expertise, experience, and commitment to customer satisfaction, you can be sure that you're in safe hands when working with them. Whether you need travel gearbox, electrical drive, travel drive,slew gearbox,winche gearbox,cutter gearbox,truck mixer gearbox,twin shaft mixer or other hydraulic transmission solutions, you can trust ELITE Hydraulic to provide you with the best possible solutions. Contact them today to learn more about their power transmission products and services.
Features:
Compact structure and space-saving design
Robust main bearing system
High torque capacity
High load capacity
Integrated static multiple disk parking brake
Optional Disconnect device for towing
Optional Quick disconnection device
Simple mounting
Easy oil change
Low-noise running operation
Specifications:
| Model | HFT180T |
| Max. output torque: | 109200 NM |
| Rated. output torque: | 43680NM |
| Input speed | up to 3,000 rpm |
| Ratio: | 91 |
| Static Brake Torque | ≥140000NM ;Spring brake, multi-disc service brakes |
| Dynamic Loading: | 1120KN |
| Static Loading: | 2170KN |
| Applicable motors: | Cartridge axial piston hydraulic motors Flanged axial piston hydraulic motors Hydraulic orbit motors Electrical motors |
| Application: | Travel for Track, Chain and Wheel driving machines ; for example bulldozer,Crawler excavator,Bracket Truck |
In conclusion, ELITE Hydraulic offers quality, value, and professional power transmission solutions that cater to a wide variety of industries. With their expertise, experience, and commitment to customer satisfaction, you can be sure that you're in safe hands when working with them. Whether you need travel gearbox, electrical drive, travel drive,slew gearbox,winche gearbox,cutter gearbox,truck mixer gearbox,twin shaft mixer or other hydraulic transmission solutions, you can trust ELITE Hydraulic to provide you with the best possible solutions. Contact them today to learn more about their power transmission products and services.
