WT390 Wheel Driving Touchless Car Wash Equipment With Foam Nozzle GQ316L
Touchless Automatic Car Washer( WT390,update version of WT360)
Features:
1.Ultrasonic induction automatically detects the distance of the car to avoid collision, which makes sure washing safer.
2.No blind angle high pressure flushing reaches 70KG or more, ensuring flushing pressure while saving energy and water
3.Automatic spray car wash foam, even and efficient decontamination, save detergent,
4.Automatic chassis inductive flushing solves the trouble that the manual washing can not handle the bottom of the car
5.Electronic touch screen control box makes sure car washing program clearly,with fault self-test and counting function .
| Parameters: | |||
| Machine Size(mm) | 7000×3100×3300 | Voltage | 380v/3phase/50HZ/16kw or other voltage |
| Mininum Installation Area Size(mm) | 7000×3300×3200 | Power consumption | 0.21kwh/Car |
| Max Vehicle Suitable(mm) | 5500×2200×2000 | Water Consumption | 150L/Car |
| Track Length(mm) | 6000 | Time | 3min/time |
| Washing Car Type | Normal and commercial vehicles, medium-sized SUV | Speed | 20cars/hour |
| Ground Flushing System | 1 set | High Pressure Nozzle | 31Pieces |
| Function | |||
| Chassis flushing | yes | Car Body Size Detecting | yes |
| Wheel rims flushing | yes | Wax Spraying | yes |
| Shampoo spraying | yes | One Button Reset | yes |
| High pressure water flushing for car body |
yes | One Button Start | yes |
| Car washing counting | yes | Fault detecting function | yes |
| Alarm Prompt | yes | External Support Frame | yes |
| Automatic Chemical Matching System | yes | Colorful Light | yes |
| Colorful Foam Spraying | yes | Remote Control | yes |
| Self-Service Payment System | yes, coins and IC card only | Washing Arm | rotate and move freely |
| External dryers | 2.2KW/pc, 4pcs total | ||
| Configuration: | |||
| Control System(PLC) | Simens PLC | Driving System | Mechanical wheel+gear wheel |
| Electric Components | Schneider | Bearing | NSK |
| Safety detecting system | BANNER | Rotary Nozzle | Nitto |
| Water Pump | Italy brand | High Pressure Nozzle | Lecheler |
| Sensor | Schneider | Frame | 1 set |
| Drive Motor | water-proof Inverter motor | Foam Nozzle | GQ316L |
