50mm Wall Car Paint Baking Oven 15KW High Speed For Car Spray Booth
Price:
$8,318.00/sets >=1 sets
MOQ:
1
Delivery Time:
25
Brand:
WINTAI
Product Description
Wall 50mm Automotive Baking Oven for CE Approved Car Paint Spraying Booth
Product Description
Guangzhou Car Paint Spraying Booth/automotive Baking Oven/auto spray booth CE approved
Configuration:
1. Wallboard: Sandwich style EPS (epispastics polystyrene) 50mm thickness. Colorful steel skin boards .Galvanized steel roof panel.
2. Basement: Galvanized steel sheet and square steel pipe construction. 3 rows of grids with floor filter & 2 rows of checkered plates. Full ramps.
3. Door: 3 pcs of luxury front doors with 0.8mm thickness colorful steel skin. Size: 3000(w) x 2600(h). 1 pc of emergency door. Watching window with aluminum frame.
4. Air Circulation System: 1 x 7.5kw direct drive intake fan, 1x5.5kw direct drive exhaust fan. BELIMO 20N electric damper
5. Burner: Italy Riello G20 diesel burner, 200000Kcal/h. The heating time 4-5min(20-60.C). Max. temperature at 80.C. Fuel consumption is 5-6kg/vehicle.
6. Heat Exchanger: Made of stainless steel. The heat exchange rate reaches 85%.
7. Lighting System: Ceiling light has 32 pcs of 18w LED lamps. Side light has 16 pcs of 18w LED lamps.1200 Lux.
8. Air Purification: Dual filtering structure. The primary filter is M pattern nonwoven filter bags. It can capture granuleslarger than 10μm. Ceiling filter capture granules bigger than 5μm. The air cleanliness in the working environment can reaches 98%.
Configuration:
1. Wallboard: Sandwich style EPS (epispastics polystyrene) 50mm thickness. Colorful steel skin boards .Galvanized steel roof panel.
2. Basement: Galvanized steel sheet and square steel pipe construction. 3 rows of grids with floor filter & 2 rows of checkered plates. Full ramps.
3. Door: 3 pcs of luxury front doors with 0.8mm thickness colorful steel skin. Size: 3000(w) x 2600(h). 1 pc of emergency door. Watching window with aluminum frame.
4. Air Circulation System: 1 x 7.5kw direct drive intake fan, 1x5.5kw direct drive exhaust fan. BELIMO 20N electric damper
5. Burner: Italy Riello G20 diesel burner, 200000Kcal/h. The heating time 4-5min(20-60.C). Max. temperature at 80.C. Fuel consumption is 5-6kg/vehicle.
6. Heat Exchanger: Made of stainless steel. The heat exchange rate reaches 85%.
7. Lighting System: Ceiling light has 32 pcs of 18w LED lamps. Side light has 16 pcs of 18w LED lamps.1200 Lux.
8. Air Purification: Dual filtering structure. The primary filter is M pattern nonwoven filter bags. It can capture granuleslarger than 10μm. Ceiling filter capture granules bigger than 5μm. The air cleanliness in the working environment can reaches 98%.
Specification
|
item
|
value
|
|
Type
|
Spray Booths
|
|
Power
|
15KW
|
|
External Size
|
7000*5540*3350mm
|
|
Internal Size
|
6900*3900*2650mm
|
|
Voltage
|
220V/380V
|
|
Disc Dia.
|
NM
|
|
No Load Speed
|
NM
|
|
Place of Origin
|
China
|
|
|
Guangdong
|
|
Brand Name
|
WINTAI
|
|
Model Number
|
WW0900
|
|
Warranty
|
1 year
|
|
Color
|
red,white, orange,blue
|
|
Wall
|
50mm
|
|
Heating System
|
diesel/gas/LPG burner
|
|
External Size
|
7000*5540*3350mm
|
|
Internal Size
|
6900*3900*2650mm
|
|
Air Flow
|
25000
|
|
Air Speed
|
0.3-0.5
|
|
Power
|
15KW
|
|
Vehicle Suited
|
Saloon Car Jeep
|
|
Warranty
|
1 year
|
Packing & Delivery
standard export package
