FRP Grating Walkway with 38mm Pultruded Phenolic Grate and Fire Retardant Fiberglass
Price:
$2.50/kilograms >=1000 kilograms
MOQ:
1000 kilograms
Delivery Time:
Negotiable
Brand:
FRP safety grating
Product Description
Products Description
Fiberglass Reinforced Phenolic Grating (FRP Grating) is a composite material made of fiberglass reinforcements embedded in a phenolic resin matrix.
2. 25mm,38mm, 40mm, 50mm,58mm,65mm high grating are available;
3-Can be cut at any lengths you need; open area is decided by customer
4.Fiberglass grating can enhance surface slip resistance by adding a layer of sand
Grating clamps are available.
Pultruded FRP grating specification list
the open area of pultruded FRP grating dimensions could be adjusted as requirement, below is popular size list
Art No. | “I”high A (mm) | “I"Top width B (mm) | "I" bottom width D (mm) | clearance C (mm) | open area | approx weight (kg/sqm） |
5025 | 25 | 30 | 30 | 30 | 50 | 10 |
4025 | 25 | 15 | 15 | 10 | 40 | 13.8 |
5025 | 25 | 15 | 15 | 15 | 50 | 11.9 |
6025 | 25 | 15 | 15 | 23 | 60 | 10 |
4038 | 38 | 15 | 15 | 10 | 40 | 20.5 |
5038 | 38 | 15 | 15 | 15 | 50 | 17.8 |
6038 | 38 | 15 | 15 | 23 | 60 | 14.8 |
6038ii | 38 | 15 | 15 | 23 | 60 | 19.2 |
4040 | 40 | 40 | 20 | 27 | 40 | 19.5 |
5040 | 40 | 40 | 20 | 40 | 50 | 17 |
6040 | 40 | 40 | 20 | 60 | 60 | 14 |
4040i | 40 | 30 | 30 | 20 | 40 | 14 |
5040i | 40 | 30 | 30 | 30 | 50 | 12 |
6040i | 40 | 30 | 30 | 45 | 60 | 10 |
6050 | 50 | 15 | 15 | 23 | 60 | 16 |
5050 | 50 | 15 | 15 | 15 | 50 | 22.5 |
4050 | 50 | 15 | 15 | 10 | 40 | 25.5 |
4058 | 58 | 15 | 15 | 10 | 40 | 32 |
5058 | 58 | 15 | 15 | 15 | 50 | 27 |
6058 | 58 | 15 | 15 | 23 | 60 | 22 |
4065 | 65 | 30 | 30 | 20 | 40 | 17 |
5065 | 65 | 30 | 30 | 30 | 50 | 15 |
6060 | 60 | 30 | 30 | 45 | 60 | 12 |
phenolic grating is commonly used on ships and offshore drilling platforms among other marine structures.
Due to the highlycorrosive and humid nature of marine environments, traditional metal materials are susceptible to corrosion and rust,necessitating corrosion-resistant alternatives to meet specific requirements.
Phenolic grating offers excellent corrosion resistance, weather resistance, and durability, capable of withstanding the harsh conditions of seawater, salt spray, UV radiation, etc.
Therefore, it is widely applied in locations such as vessels, offshore platforms, docks, and marine structures, serving as construction materials for flooring, platforms, walkways, and safety railings, among other facilities.
offshore platform walkway
Ship decking
Related Product
FRP Handrail/Fence/Guardrail
FRP Stair Step Ladder With Handrail
FRP Step Ladders
FRP Support Beam For Grating Floor
FRP Structural Profiles
FRP Molded Grating
Antislip FRP Decking Strip
FRP Handrail Fittings
FRP Cable Tray
Packing And Shipping
Packing type: pallets, wood carton, etc. also could packing according to customer's requirement.
Shipping： land shipping, air shipping, railway shipping, express delivery(length can't over 2.5m)
