High Quality 360 Degree Safety Valves and Actuator Tinplate Material for Chemical Use Aerosol
Precise and efficient spraying
The one-inch industrial-grade valve design is suitable for high-viscosity or liquids that require quantitative spraying. It features a stable flow rate and can meet various working conditions such as lubrication, cleaning, and rust prevention.
It can be used at any 360° Angle
It is not restricted by position, supports inverted spraying, and is suitable for complex workstations and hard-to-reach parts surfaces.
Specifications:
| Component | Part No. | Part Description |
| Mounting cup | 1-F2 | Both sides with clear lacquered tinplate ,with down dimples |
| Outer gasket | 1-G1 | Buna |
| Inner gasket | 1-B4 | Neoprene |
| Stem | 1-A7 | Orange color, double orifice 2X diameter 0.51mm |
| Spring | 1-C1 | Stainless steel |
| Housing | 1-D1 |
all direction valves housing tail orifice: diameter 2.0mm with stainless steel ball white |
-
Question:What is your terms of payment of 360 Degree spray valve?
Answer:Payment<=10000USD,100% in advance.
Payment>=10000USD,30% T/T in advance ,balance before shippment.
Question:Do you have any MOQ limit for 360 Degree spray valve?
Answer:Low MOQ, 1pc for sample checking is available.
Question:How do you ship the goods and how long does it take to arrive?
Answer:Ship by DHL, UPS, FedEx or TNT. It takes 3-5 days to arrive.
Airline and sea shipping also optional.
