Off Grid And Grid Tied Operations With Built In WiFi Hybrid Inverters
Hybrid Inverters for Off-Grid and Grid-Tied Operations with Built-In WiFi
Product Description
This high-efficiency Pure Sine Wave Solar Inverter provides seamless integration for solar energy systems, offering a maximum efficiency of 98%. Equipped with built-in MPPT technology, it ensures optimal solar power conversion and battery charging. The inverter supports both off-grid and grid-tied operations, with dual output capabilities for increased flexibility. It is compatible with lithium batteries and is designed to operate without a battery if necessary. The integrated smart battery charging system optimizes battery life, while the anti-dust kit ensures the inverter performs well even in harsh environments. Additionally, this product comes with built-in WiFi and GPRS compatibility for easy monitoring and control via mobile applications on iOS and Android.
| MODEL SY-1.0K12 SY-1.5K24 | ||
| Rated Power | 1000W/1000VA | 1500W/1500VA |
| ACINPUT | ||
| Voltage | 230VAC | |
| Selectable VoltageRange | 170~280VAC(For PersonalComputers) | |
| 90~280VAC(For Home Appliances) | ||
| Frequency Range | 50Hz/60Hz(Auto sensing) | |
| ACOutput | ||
| AC VoltageRegulation | 230VAC±5% | |
| SurgePower | 4000VA | 6400VA |
| Efficiency(Peak)PVto INV | 98% | |
| Efficiency(Peak)Battery to INV | 94% | |
| Transfer Time | 10ms(For Personal Computers);,20ms(For Home Appliances) | |
| BATTERY &AC CHARGER | ||
| Battery Voltage | 12VDC | 24VDC |
| Floating Charge Voltage | 13.5VDC | 27VDC |
| Overcharge Protection | 16VDC | 33VDC |
| SOLAR CHARGER &ACCHARGER | ||
| Solar Charge Type | MPPT | |
| Maximum PVArray Power | 600W | 1200W |
| MPPT Range @Operating Voltage | 20-150VDC | 30-150VDC |
| MaximumPVArray OpenCircuit Voltage | 150VDC | |
| Maximum Solar Charging Current | 40A | |
| Maximum AC Charging Current | 40A | |
| Maximum Charging Current(Solar+AC) | 80A | |
| PHYSICAL | ||
| Dimension,D×WxH(mm) | 290*240*91 | |
| Carton Dimension,D×W×H(mm) | 340*275*145 | |
| Net Weight(kgs) | 3 | 3.5 |
| GrossWeight(kgs) | 3.5 | 4 |
| ENVIRONMENT | ||
| Humidity | 5%to 95%Relative Humidity(Non~condensing) | |
| Operating Temperature | -10℃~50℃ | |
| STANDARD | ||
| ComplianceSatety | CE | |
Application
This inverter is ideal for residential and commercial applications where reliability and performance are critical. It is perfect for use in areas with unstable grid power, offering smooth transition and energy independence. The device’s flexibility to operate both with and without batteries makes it suitable for a wide range of installation scenarios, from remote locations to urban areas. It is also an excellent option for users seeking to reduce their dependence on grid power and maximize the use of solar energy.
