6KW 8KW 11KW Hybrid Inverters 51.2V 200Ah For Various Battery Types
Intelligent Battery Management for Various Battery Types Hybrid Inverters
Product Description
The ALPHA ESS Energy Solar System is a highly efficient and reliable energy storage solution designed to provide sustainable power for residential and commercial applications. With an integrated hybrid MPPT inverter and built-in LiFePo4 battery, this energy storage system ensures maximum power generation from solar panels while storing excess energy for later use. The system is equipped with advanced features such as a smart BMS for enhanced battery management, modular and stackable designs for easy installation and expansion, and a user-friendly Wi-Fi monitoring system for remote operation. With a life cycle of over 6000 cycles, this system guarantees long-lasting performance and durability, meeting the high standards of modern energy demands.
| SPECIFICATION | ALPHA ESS 6K/10KWh | ALPHA ESS 8K/15KWh | ALPHA ESS 11K/15KWh |
| INVERTER /CHARGER | |||
| Inverter Type | Hybrid MPPT Inverter | ||
| Rated Output Power | 6KW | 8KW | 11KW |
| Output Voltage Waveform | Pure Sine Wave | ||
| Output Voltage | 230VAC 50HZ | ||
| Low DC Warning Voltage | 45.8Vdc | ||
| Low DC Cut-off Voltage | 44.8Vdc | ||
| Low DC Warning Return Voltage | 46.8Vdc | ||
| Total Charging Current(Grid+solar) | 120AMax | 150A Max | 150A Max |
| Bulk Charging Voltage | 57.6Vdo | ||
| Float Charging Voltage | 56.0Vdc | ||
| LITHIUM IR ON BATTERY | |||
| NormalBatteryModular | 51.2V200Ah | 51.2V300Ah | 51.2V300Ah |
| NormalCapacity(25℃,0.2C) | 10.24KWh | 15.36KWh | 15.36KWh |
| NominalBatteryVoltage | 51.2Vdc | 51.2Vdo | 51.2Vdo |
| NominalCapacity | 200Ah | 300Ah | 300Ah |
| Max.ChargeCurrent | 225A 1Sec. | 300A 1Sec. | 300A 1Sec. |
| Max.DischargeCurrent | 150A | 200A | 200A |
| OperationVoltageRange | 44.8Vdc～58.4Vdc | ||
| OperationTemperature | -10℃~+50℃ | ||
| AC INPUT | |||
| Nominal Input Voltage | 230Vac | ||
| Low Loss Voltage | 170Vac±7(UPS),90Vac±7(Appliances) | ||
| Low Loss Returm Voltage | 180Vac±7(UPS),100Vac±7(Appliances) | ||
| High Loss Voltage | 280Vac±7 | ||
| High Loss Returm Voltage | 270Vac±7 | ||
| Max.AC Input Voltage | 300Vac | ||
| Nominal Input Frequency | 50HZ/60HZ(Auto detection) | ||
| AC Charging Current | 120A Max. | 150A Max. 150A Max. | |
| SOLAR INPUT | |||
| Nominal PV Voltage | 360Vdc | ||
| PVArray MPPT Voltage Range | 120Vdc~450Vdc | ||
| Max.PVAmay Open Crcuit Voltage | 500Vdc | ||
| Solar Charging Current | 120A Max. | 150A Max. 150A Max. | |
| PROTECTION | |||
| Protection | Over charge protection,Over discharge protection,Over currentprotection, Shortcircuit protection,Over temperature protection |
||
| AMBIENT | |||
| Noise(dB) | <55dB (1 meter) | ||
| Working Temperature | -10℃~+50℃ | ||
| Humidity | 0~95%(no condensation) | ||
| Sea Level(m) | ≤1500 | ||
| OTHERS | |||
| Eficiency | 92.0% | ||
| Warranty | 1 Year for Inverter,3 Years for Lithium Battery | ||
Application
This energy storage system is ideal for:
- Residential homes seeking reliable backup power
- Commercial facilities aiming to reduce electricity costs through solar energy
- Off-grid locations that need a stable and continuous power supply
- Sustainable energy solutions in remote or rural areas
- Backup systems for critical infrastructure during outages
Shipping Methods
Supports global air and sea shipping.
