Solar Hybrid Inverter System For Residential And Small Commercial Energy Needs
The SUNON-ECO Hybrid Inverters for Residential and Small Commercial Energy Needs
Product Description:
The SUNON-ECO series is a high-performance hybrid inverter designed for off-grid and grid-tied solar systems. Equipped with a built-in 120A MPPT solar charge controller, it offers efficient energy conversion with a peak efficiency of 98%. The inverter supports pure sine wave output, ensuring compatibility with sensitive electronics and home appliances. With its robust battery management system, the SUNON-ECO inverters provide seamless operation with or without batteries, making it suitable for various power needs. Available in 4.2KVA and 6.2KVA models, the SUNON-ECO series is ideal for residential and small commercial applications requiring reliable and efficient power solutions.
| NEW MODEL | SUNON-EC04.2KVA | SUNON-ECO 6.2KVA |
| Max.PV Power | 5000W | 6500W |
| Rated Power | 4200VA | 6200VA |
| Max.Charge Current | 120A | 120A |
| BATTERY | ||
| Battery Voltage | 24VDC | 48VDC |
| Floating Charge Voltage | 27VDC | 54VDC |
| Overcharge Protection | 33VDC | 63VDC |
| Battery Type | Compatible with GEL,AGM,Llithium Battery | |
| GRID INPUT | ||
| Voitage | 230 VAC | |
| Selectable Voltage Range | 170-280VAC(ForPersonal Computers);90-280 VAC(For Home Appliances) | |
| Frequency Range | 50 Hz/60 Hz(Auto sensing) | |
| Efficiency(AC Mode) | 98% | |
| AC OUTPUT | ||
| AC Voltage Regulation (Batt.Mode) | 230 VAC±5% | |
| Surge Power | 8400VA | 12400VA |
| Efficiency(Peak) | 90%~94% | |
| Transfer Time | 10 ms(For Personal Computers);20 ms(For Home Appliances) | |
| Waveform | Pure sine mave | |
| DUALLOADS AC OUTPUT | ||
| Full Load | 4200VA | 6200VA |
| Maximum Main Load | 4200VA | 6200VA |
| Maximum Second Load (Battery Mode) | 1200W | 2100W |
| Main Load Cut Off Voltage | 22VCD | 44VCD |
| Main Load Retum Voltage | 27VCD | 54VCD |
| SOLAR CHARGER&AC CHARGER | ||
| Solar Charger Type | MPPT | |
| Maximum PV Array Power | 5000W | 6500W |
| Max.input Current | 27A | 27A |
| MPPT Range @Operating Voltage | 90~450VDC | 90~450VDC |
| Maximum PVArray Open Circuit Voltage | 500 VDC | |
| Maximum Solar Charge Current | 120A | 120A |
| Maximum AC Charge Curent | 100A | 100A |
| Maximum Charge Curent | 120A | 120A |
| PHYSICAL | ||
| Packing Dimension,DXWXH(mm) | 543*394*204 | 543*394*204 |
| Net Weight (kgs) | 9.8 | 10.5 |
| Communication Interface | USB/RS232WIFIVGPRS | |
| OPERATING ENVIRONMENT | ||
| Humidity | 5%to 95%Relative Humidity(Non-condensing) | |
| Operating Temperature | -10℃ to 50℃ | |
| Storage Temperature | -15℃ to 60℃ | |
| Product specifications are subject to change without further notice. | ||
Application:
The SUNON-ECO series is ideal for residential and small commercial applications where consistent and reliable power is required. It supports both off-grid and grid-tied setups, offering flexibility in energy management. With dual AC outputs, this inverter can feed power back to the grid, making it suitable for homes, offices, and small businesses. It also supports a wide PV input voltage range (90V–450VDC) and integrates a smart battery charge controller, ensuring optimal performance for solar energy storage systems.
