Steel Q235 Heavy Duty Assembled Warehouse Pallet Rack / Metal Storage Racks

Highlight:Hot Sales Heavy Duty Assembled Warehouse Pallet Racks Warehouse Racking Metal Storage Racks

DESCRIPTION:

The heavy pallet rack is assembled by columns, beams, cross braces, slant support and self-locking bolts, which can effectively prevent the rack from losing stability after the bolts are loose; The crossbeam adopts a specially cold-rolled P-type closed beam; This structure has the characteristics of simplicity, reliability, light weight, strong bearing capacity, and low cost; The column clamp is equipped with a specially designed safety pin when connected to the column, which can ensure that the crossbeam will not fall off under external impact; The laminated board adopts steel plate bent bottom reinforced laminated board, which has the characteristics of strong bearing capacity, wear resistance, easy replacement, and low maintenance cost.

pallet rack Advantage:
1. Heavy duty crossbeam racks are used in various industries, with low cost, safety and reliability, simple assembly and disassembly, and can be used separately or arranged freely in the form of main and auxiliary racks.
2. The column pieces of the heavy cross beam shelf are connected by the columns, cross braces and slant support with bolts; The shelf frame is composed of column and beam connectors, which are fixed with safety pins and have a simple and reliable structure; The steel layer board is placed on top of the closed crossbeam to form the overall shelf. Each layer can be freely adjusted up and down with a step distance of 75mm.
3. Heavy duty crossbeam racks can determine the layer load requirements based on the size of the crossbeam, the thickness of the layer board, and the number of reinforcing ribs. With the relative length and material selection requirements met, the maximum layer load can reach 2500kg/layer.
