Underground Cable Fault Locator with 0.2m Accuracy
Price:
Negotiable
MOQ:
1 unit
Delivery Time:
5-8 work days
Brand:
XZH TEST
Product Description
XHDD503C Underground Cable Fault Pinpoint Locator
Introduction
The XHDD503C is a professional power cable fault locator adopting acoustic and magnetic synchronization technology. It detects electronic flashover from an impact discharge generator via a specialized probe, achieving precise positioning through auditory and visual analysis within rough measurement ranges while collecting acoustic-magnetic signal time differences.
Features
- 5-inch high-brightness touch LCD with sunlight visibility
- Acoustic-magnetic synchronous positioning technology with automatic time difference calculation and manual adjustment capability
- Advanced background noise reduction with multiple filtering options and path deviation indication
- Multi-layer physical isolation signal sensors with IP65 waterproof rating
- Built-in large-capacity lithium battery with extended standby time and fast charging capability
- Compact, lightweight design with intuitive operation and simple user interface
Technical Specifications
| Parameter | Specification |
|---|---|
| Filter Parameters | All-pass: 100Hz~1600Hz, Low pass: 100Hz~300Hz, Qualcomm: 160Hz~1600Hz, Bandpass: 200Hz~600Hz |
| Output Impedance | 350Ω |
| Acoustomagnetic Positioning Accuracy | < 0.2m |
| Path Identification Accuracy | < 0.5m |
| Standby Time | > 8 hours |
| Operating Temperature | -25~65℃ |
| Relative Humidity | ≤90% |
