Xzh Test Xhhv515-8L 0-15kv Automatic Discharge Type High -Voltage Electric
Product Description
This device integrates a DC high-voltage source, energy storage capacitor, discharge ball gap, etc. It completely replaces the traditional test transformer, operating box and pulse energy storage capacitor weighing hundreds of kilograms.
Features
★ Automatic protection against overcurrent, overvoltage, and overheating;
★ High-voltage pulse output consistent and controllable;
★ Super short-circuit protection grounds high-voltage output safely;
★ Dual pointer displays for clear current and voltage monitoring;
★ Accurate high-voltage side voltage measurement in real-time;
★ Zero-start protection and potentiometer zero-return function ensure reliability;
★ Real-time capacitor voltage monitoring during stopped state;
★ Adjustable discharge time within a suitable interval.
Technical Parameters
| Impact voltage | 0~15kV |
| High voltage partial pressure | Level 2.5 |
| Built-in capacitor | 8μF |
| Discharge power | 0~900J |
| Output voltage polarity | negative polarity |
| Impact power | 400W |
| Overcurrent protection | 10A (more than 3 seconds) |
| Over-temperature protection | 65ºC |
| Volume | 540L×300W×450H |
| Weight | no more than 25kg |
| Working power supply | AC 220V±10%/50Hz±2Hz |
| Ambient temperature | -20~+60ºC |
