This device is an integrated unit that includes a DC high - voltage source, energy storage capacitor and discharge ball gap. It streamlines the testing process by replacing the traditional test transformer, operating box and pulse energy storage capacitor, which used to have a combined weight of hundreds of kilograms.

   Features

   ★ With automatic protection functions for overcurrent, overvoltage and overheating;
   ★ High voltage pulse output is uniform and controllable;
   ★Super short-circuit protection function, which can make the high-voltage output directly short-circuit to ground;
   ★ It has dual 2.5-level pointer display for current and voltage, which is intuitive and clear, and the impact discharge process is clear at a glance;
   ★ High-voltage side voltage measurement, real-time and accurate;
   ★ It has zero start protection and potentiometer zero return output function, safe and reliable;
   ★ Unique high-voltage measurement design, in the stopped state, the voltmeter can indicate the capacitor voltage in real time;
   ★ The discharge time can be set arbitrarily within the appropriate interval;

Technical Parameters
