High Voltage Cable Fault Locator with Open-circuit Voltage 15kV for Precise Detection of Outer Sleeve Failure
Price:
Negotiable
MOQ:
1set
Delivery Time:
5-8 work days
Brand:
XZH TEST
Product Description
XHHG521C-L Power Cable Fault Locator
Professional test equipment for detecting and locating outer sleeve failures in power cables with an open-circuit voltage of 15kV.
The cable sheath fault tester is designed based on the Murray bridge principle and can be used to locate breakdown points in various wires and cables, as well as defects that are not broken down but have low insulation resistance values.
The equipment uses an electric voltage regulator and an R-type transformer to form a high-voltage constant current source, with button operation for increasing and decreasing the voltage.
Product Features
- Specialized equipment for power cable fault detection
- Effective for identifying outer sleeve failures
- High voltage capacity with 15kV open-circuit voltage
- Essential tool for power system maintenance
- Withstand voltage section
- Automatic protection against overcurrent, overvoltage, and overheat;
- Zero-position start protection for enhanced safety and reliability;
- Unique self-discharge design—its own high voltage drops to zero as soon as the high-voltage output is cut off
- Dual pointer display for current and voltage, providing clear and intuitive readings;
- Overcurrent protection switch function.
| Key Specification | Value |
|---|---|
| Equipment Type | Power Cable Fault Locator |
| Primary Application | Outer sleeve failure detection |
| Open-circuit Voltage | 15kV |
|
Input voltage |
220V (±10%), 50Hz (±2Hz) |
| Output voltage | 0～15kVDC adjustable |
| Output current | 0～150mA |
| Output capacity | 2kVA |
