ZCX Series Superfine Separator sorting equipment
ZCX Series Superfine Separator sorting equipment Direct Connection And Belt Drive For Chemical Products Pesticides
ZCX Series Superfine Separator
1.Direct connection and belt drive,adopting new design,high classification accuracy and more reasonable design configuration.
2.High yield,low energy consumption,accurate vertex cutting,multi-stage series connection,and multiple particle size products at the same time.
Application
Chemical products,pesticides,medicine,ceramics,ceramsite sand,refractories,food,new materials,minerals (calcium carbonate,kaolin,quartz,talc,barite,graphite and other non-metallic minerals)
Technical data
|
Parameters (D97:μm) Type Product Fineness |
Input Capacity(t/h) |
Power (kw) Airflow(m³/h) |
||
| ZCX132 | 5~150 | 0.01~0.1 | 4 | 600 |
| ZCX200 | 5~150 | 0.02~0.2 | 5.5 | 1500 |
| ZCX300 | 5~150 | 0.2~1 | 7.5 | 2500 |
| ZCX360 | 6~150 | 0.8~2.5 | 11 | 3500 |
| ZCX450 | 8~150 | 1.5~5 | 18.5 | 5500 |
| ZCX550 | 8~150 | 2.5~6 | 22 | 7500 |
| zCX600 | 8~150 | 4~10 | 30 | 10000 |
| ZCX750 | 8~150 | 6~12 | 37 | 15000 |
| ZCX900 | 10~150 | 8~15 | 45 | 22000 |
| ZCX1000 | 15~150 | 12~20 | 55 | 28000 |
| ZCX1250 | 18~150 | 20~35 | 75/90 | 45000 |
| ZCX1400 | 15~150 | 30~40 | 90 | 50000 |
| ZCX1600 | 15~150 | 35~45 | 110 | 60000 |
| zCX2000 | 15~150 | 40~60 | 110/132 | 90000 |
| ZCX2200 | 18~150 | 60~80 | 132/160 | 110000 |
| ZCX2500 | 20~150 | 80~120 | 160/185 | 150000 |
| ZCX3000 | 25~150 | 150~200 | 185/200 | 180000 |
