Product Description
Product Usage
1. Definition of a TractorA tractor is a highly versatile light truck designed to perform the vital role of towing various vehicles or objects on the road. Equipped with multiple pairs of wheels and axles, it becomes an essential asset for pulling an extensive range of items, from semi-trailers and luxury yachts to heavy construction machinery. This incredible flexibility and power make it a backbone in heavy transport operations.
2. Structure of a Tractor
At its core, a tractor is composed of an engine, transmission, tires, and frame. Its capabilities are significantly enhanced by incorporating additional equipment such as tow hooks, advanced locking mechanisms, and cutting-edge remote controls. These features offer extraordinary operational efficiency and precise maneuverability.
3. Application Fields for Tractors
1. Transportation: In the long-haul freight industry, the tractor is indispensable for towing semi-trailers and other large trucks. It ensures the secure and efficient transportation of goods, making it a critical tool in logistics.
2. Construction: Tractors are fundamental in the construction industry for towing heavy machinery like excavators,bulldozers, and cranes. These powerful machines are typically moved to construction sites using tractors, ensuring seamless project execution.
Basic Information
Basic Information
| driver license: | A2 | Announcement Model: | BJ4253SNFJB-S4 |
| Drive type: | 6X2 | Wheelbase: | 1800+2700mm |
| engine: | Dongfeng Cummins ISLe340 30 | Rear axle ratio: | 4.111 |
| Body length: | 7.18 m | Body width: | 2.495 m |
| Ride height: | 3.41 m | Front track: | 2020/2020mm |
| Rear track: | 1800mm | Vehicle weight: | 7.765 tons |
| Total mass: | 25 tons | Total traction mass: | 38.04 tons |
| Maximum speed: | 86km/h | Origin: | Beijing |
| Tonnage level: | Heavy Truck | Remark: | ISLe340 30 engine power is net power, corresponding to the standard support weight of 38040, optional 06 flat-top ETX cab |
| Fuel Type: | diesel fuel | | |
Engine parameters
| engine model: | Dongfeng Cummins ISLe340 30 | Engine Brand: | Dongfeng Cummins |
| Number of cylinders: | 6 cylinders | Fuel type: | diesel fuel |
| Cylinder arrangement: | In-line | Displacement: | 8.9L |
| Emission Standards: | National Three | Maximum horsepower: | 340 hp |
| Maximum output power: | 250kW | Maximum Torque: | 1425N·m |
| Maximum torque speed: | 1100-1400rpm | Rated speed: | 2100rpm |
Cab parameters
| Cab: | High Top | Number of passengers allowed: | 3 people |
| Number of Seat Rows: | Half row | | |
Gearbox parameters
| Gearbox Model: | Fast 12JS160TA | Gearbox brand: | Fast |
| Shifting method: | Manual | Forward gears: | 12 gears |
| Reverse gear number: | 2 | | |
tank
| Fuel tank/gas tank material: | Aluminum Alloy | Fuel tank capacity: | 350L |
Chassis parameters
| Rear Axle Description: | 485 single reduction bridge | Permissible load on rear axle: | 11500kg |
| Speed ratio: | 4.111 | Suspension type: | Leaf spring |
| Number of springs: | 11/11/9+6 | | |
tire
| Number of tires: | 8 | Tire specifications: | 11.00-20 |
Key Specifications:
Driver's Cab (Features one sleeper with air conditioning for maximum comfort)
| Model | H7 Cab, with one sleeper beds, two seats, with A/C |
| Type | Forward control cab, hydraulically tiltable by 60 degrees |
| Construction | Current standard all steel construction |
| Instrument panel | Clearly visible, indicators of compressed air pressure, coolant temperature, engine oil pressure and battery charging |
| Seats | 4-point support fully floating suspension + shock absorbers driver adjustable & passenger fixed |
| Seat belts | For driver & passenger |
| Glass | Tempered safety glass |
| Sun visors | Dual, adjustable |
| Mirrors | Large, truck type convex |
| Wind screen wiper | 3 arm wind screen wiper system with 3 speeds |
| Entertainment system | FM/AM/SW, 4-band radio with cassette player, two speakers and antenna |
| Steering wheel | Adjustable steering wheel |
| Horn | Air horn |
| Panel | LCD Panel with LED light |
Engine Specifications
| Engine brand | SINOTRUK |
| Engine model | WD615.47, 380hp |
| Emission Standard | EURO 6 |
| Engine type | Diesel 4-stroke direct injection engine, 6-cylinder in-line with water cooling, turbo-charging & Inter-cooling |
| Displacement | 9.726 liters |
| Max. Output | 371hp@2200rpm |
| Max. torque | 1250Nm @1100-1600 rpm |
| Bore/Stroke | 126/130mm |
| Compression ratio | 17:1 |
| Specific fuel consumption | ≤193g/kW.h |
Cooling System Details
| Medium | Water |
| Radiator | Heavy-duty type |
| Cooling fan | Visco static fan tropical type |
| Thermostat | Opening at 70-80ºC |
| Warning device | Audible & visual |
Clutch System
| Type | Φ430 Diaphragm type, Single dry frictional disc, Hydraulic boosting hydraulically operating with air assistance |
Transmission Mechanism
| Type | Heavy duty, manual fuller type | ||||||||||||||||
| Model | HW19710 | ||||||||||||||||
| No speeds | 10 forward + 2 reverse | ||||||||||||||||
| Model | Torque(Nm) | Gear Ratios | Oiling (L) | ||||||||||||||
| 1 | 2 | 3 | 4 | 5 | 6 | 7 | 8 | 9 | 10 | R1 | R2 | ||||||
| HW19710 | 1900 | 14.28 | 10.62 | 7.87 | 5.88 | 4.38 | 3.27 | 2.43 | 1.80 | 1.34 | 1.00 | 13.91 | 3.18 | 12 | |||
Front Axle
| Type | HF7 tons steering with double T-cross section beam |
| Capacity | 7000kg |
Rear Axle
| Type | HC16 (16 ton, punching-welding axle housing, double reduction driving axle, inter-wheel differential and differential lock) |
| Capacity | 16T |
Chassis Configuration
| Frame | Heavy duty, reinforced sub frame, 300mmx80mmx8mm (inner: 280mmx70mmx7mm) |
| Front suspension | semi-elliptic leaf springs with hydraulic telescopic double-action shock absorbers and stabilizer, 1500mm |
| Rear suspension | semi-elliptic springs ,and bogie springs, and stabilizer , 1739mm |
Air Intake System
| Air cleaner type | Heavy duty type |
| Pre filter | Cyclone |
Exhaust System
| Capable of maintaining the sound level as low as possible. |
Steering System
| Location | Left hand |
| Model | ZF 8098 (Made in Germany) hydraulic steering with power assistance |
| Variable ratios | 22.2-26.2, 17.0-20.0 |
| Max. pressure | 170+10 bar |
| Max. output torque | 7618 Nm |
| Weight | 42 kg |
Bumper Details
| Installed heavy duty front and rear steel bumpers |
Brake System
| Service brake | Dual circuit compressed air brake. |
| Parking brake | Spring energy, compressed air operating on rear wheels |
| Assistant brake | Engine exhaust valve brake |
Wheels & Tires Information
| Wheels | Single front and dual rear |
| Tyres | Double Coin brand,12.00R20 |
| Quantity | 13 |
Air Supply System
| Warning device | Audible & visual |
| Air line | Heavy duty steel pipes |
Electrical System
| Operating Voltage | 24V, Negative grounded; Starter 24V, 7.5KW |
| Battery type | 2x12V, 165Ah/180Ah |
| Alternator | 28V, 1500W |
| Cigar | Lighter, horn, head lamps, fog lights, brake lights, indicators and reverse lamp |
Dimensions
| Wheel base | 4600mm+1350 |
| Overall length | 6875mm |
| Overall width | 2496mm |
| Overall height | 3730mm |
Our Manufacturing Facility
Shipment Details
We typically ship our trucks using RO-RO vessels or bulk carriers. For enhanced flexibility, specialized containers can also be utilized to transport the trucks.
Genuine Spare Parts
We supply authentic spare parts. Our extensive after-sales service, managed by our After-market Division, ensures exceptional support and utilizes an efficient supply chain for rapid parts delivery.
