Comfortable Air Suspension Seat for Semi Trailer on HOWO Heavy Duty Towing Truck
Price:
Negotiable
MOQ:
Negotiable
Delivery Time:
7-15days
Product Description
Product Use
1. Definition of Tractor
A tractor is a versatile powerhouse designed for towing vehicles or objects on the road. Equipped with one or more pairs of wheels and axles, it is crucial in transporting heavy loads such as semi-trailers, luxury yachts, and construction equipment. Unmatched in reliability and strength, it revolutionizes the transportation of substantial cargo.
2. Structure of the Tractor
A tractor is comprised of several critical components: engine, transmission, tires, and frame. To enhance its capabilities, it can be equipped with advanced devices such as tow hooks, locking systems, and remote controls, ensuring superior operational control and performance.
3. Tractor Application Fields
1. Transportation: Tractors are indispensable in the long-distance freight industry, pivotal for towing semi-trailers and large trucks, ensuring the safe and efficient delivery of goods over vast distances.
2. Construction: Tractors are essential in construction, towing heavy equipment like excavators, bulldozers, and cranes to various sites, facilitating large-scale projects with ease and efficiency.
Basic Info.
| Horsepower | 251-420hp | Engine Capacity | >8L | |
| Tire Design | Radial | Condition | New | |
| Usage | Towing Semi Trailer | Fuel Tank | 400L, 600L, 1000L | |
| Driver Seat | Air Suspension Seat | Transport Package | Nude Packing | |
| Trademark | SINOTRUK HOWO | Production Capacity | 1000 |
Main Specifications:
Driver's Cab(One sleeper with A/C)
| Model | HW76 Cab, with one sleeper beds, two seats, with A/C |
| Type | Forward control cab, hydraulically tiltable by 60o |
| Construction | Current standard all steel construction |
| Instrument panel | Clearly visible,indicators of compressed air pressure, coolant temperature, engine oil pressure and battery charging |
| Seats | 4-point support fully floating suspension + shock absorbers driver adjustable & passenger fixed |
| Seat belts | For driver & passenger |
| Glass | Tempered safety glass |
| Sun visors | Dual, adjustable |
| Mirrors | Large, truck type convex |
| Wind screen wiper | 3 arm wind screen wiper system with 3 speeds |
| Entertainment system | FM/AM/SW, 4 band radio with cassette player, two speaker and antenna |
| Steering wheel | Adjustable steering wheel |
| Horn | Air horn |
| Panel | LCD Panel with LED light |
Engine
| Engine brand | SINOTRUK |
| Engine model | WD615.47, 380hp |
| Emission Standard | EURO II |
| Engine type | Diesel 4-stroke direct injection engine, 6-cylinder in-line with water cooling, turbo-charging & Inter-cooling |
| Displacement | 9.726 liters |
| Max. Output | 371hp@2200rpm |
| Max. torque | 1250Nm @1100-1600 rpm |
| Bore/Stroke | 126/130mm |
| Compression ratio | 17:1 |
| Specific fuel consumption | ≤193g/kW.h |
Cooling System
| Medium | Water |
| Radiator | heavy duty type |
| Cooling fan | Visco static fan tropical type |
| Thermostat | Opening at 70-80ºC |
| Warning device | Audible & visual |
Clutch
| Type | Φ430 Diaphragm type, Single dry frictional disc, Hydraulic boosting hydraulically operating with air assistance |
Transmission
| Type | Heavy duty, manual fuller type | ||||||||||||||||
| Model | HW19710 | ||||||||||||||||
| No of speeds | 10 forward + 2 reverse | ||||||||||||||||
| Model | Torque(Nm) | Gear Ratios | Oiling (L) | ||||||||||||||
| 1 | 2 | 3 | 4 | 5 | 6 | 7 | 8 | 9 | 10 | R1 | R2 | ||||||
| HW19710 | 1900 | 14.28 | 10.62 | 7.87 | 5.88 | 4.38 | 3.27 | 2.43 | 1.80 | 1.34 | 1.00 | 13.91 | 3.18 | 12 | |||
Front Axle
| Type | HF7 tons steering with double T-cross section beam |
| Capacity | 7000kg |
Rear Axle
| Type | HC16(16 ton, punching-welding axle housing, double reduction driving axle, inter-wheel differential and differential lock) |
| Capacity | 16T |
Chassis
| Frame | Heavy duty, reinforced sub frame, 300mmx80mmx8mm (inner: 280mmx70mmx7mm) |
| Front suspension | semi-elliptic leaf springs with hydraulic telescopic double-action shock absorbers and stabilizer, 1500mm |
| Rear suspension | semi-elliptic springs ,and bogie springs, and stabilizer , 1739mm |
Air Intake System
| Air cleaner type | Heavy duty type |
| Pre filter | Cyclone |
Exhaust System
| Capable of maintaining the sound level as low as possible. |
Steering
| Location | Left hand |
| Model | ZF 8098 (Made in Germany) hydraulic steering with power assistance |
| Variable ratios | 22.2-26.2, 17.0-20.0 |
| Max. pressure | 170+10 bar |
| Max. output torque | 7618 Nm |
| Weight | 42 kg |
Bumper
| Installed heavy duty front and rear steel bumpers |
Brake System
| Service brake | Dual circuit compressed air brake. |
| Parking brake | Spring energy, compressed air operating on rear wheels |
| Assistant brake | Engine exhaust valve brake |
Wheels & Tyres
| Wheels | Single front and dual rear |
| Tyres | Double Coin brand,12.00R20 |
| Quantity | 13 |
Air Supply System
| Warning device | Audible & visual |
| Air line | Heavy duty steel pipes |
Electrical System
| Operating Voltage | 24V, Negative grounded; Starter 24V, 7.5KW |
| Battery type | 2x12V, 165Ah/180Ah |
| Alternator | 28V, 1500W |
| Cigar | Lighter, horn, head lamps, fog lights, brake lights, indicators and reverse lamp |
Dimensions
| Wheel base | 4600mm+1350 |
| Overall length | 6875mm |
| Overall width | 2496mm |
| Overall height | 3730mm |
Our Factory
Shipment
We typically ship the truck via RO-RO or bulk vessel, and can also use specialized containers for transportation, ensuring that your vehicle arrives in pristine condition.
Original Spare Parts
We provide original spare parts backed by a comprehensive after-sales service system. Our After-market Division ensures excellent service and rapid parts delivery through an efficient and responsive supply chain.
Our Product
Thanks for Choosing Us
Q: How about the delivery time?
A: Most of our trucks and machines are in stock, enabling quick delivery within 7 days. For specially ordered items, we typically require around 30 days for production.
Q: How many units of trucks do you produce per year?
A: We produce nearly 30,000 units annually, with an impressive update rate of almost 5,000 units per month.
Q: How do you control the quality of your products?
A: Our factory adheres to stringent production standards, employing highly skilled workers. Each product undergoes a rigorous inspection process to ensure top-notch quality. We also professionally recondition our trucks and machinery.
Q: Do you accept custom orders? What's your MOQ?
A: Yes, we accept custom orders. Our minimum order quantity (MOQ) is 1 unit, making it easy for you to get exactly what you need.
Q: How about the delivery time?
A: Most of our trucks and machines are in stock, enabling quick delivery within 7 days. For specially ordered items, we typically require around 30 days for production.
Q: How many units of trucks do you produce per year?
A: We produce nearly 30,000 units annually, with an impressive update rate of almost 5,000 units per month.
Q: How do you control the quality of your products?
A: Our factory adheres to stringent production standards, employing highly skilled workers. Each product undergoes a rigorous inspection process to ensure top-notch quality. We also professionally recondition our trucks and machinery.
Q: Do you accept custom orders? What's your MOQ?
A: Yes, we accept custom orders. Our minimum order quantity (MOQ) is 1 unit, making it easy for you to get exactly what you need.
