LP20 Series 20A IP68 3-Pin Waterproof In-Line Connector
Price:
The price ranges from $1 to $4 USD per pieces
MOQ:
100PCS
Delivery Time:
5-8 Working Days
Brand:
Cablein
Product Description
LP20 Series 20A IP68 3-Pin Waterproof In-Line Connector
Specifications
Pin: 3 Pin
Current Rating(A): 20A Max
Material: Metal+plastic
Conenction Way: Push-button snap fastener
Operating Voltage: 500V Max
Assembly Wire: IP-Rated Locking Gland
Mounting Type: Flange Mounting Type
Out Door UV Resistance: Pass
Cable Jacket OD: 2.5-4 mm²
Datasheet
| Pins Number | 2Pins | 3Pins | 4Pins | 5Pins | 7Pins | 9Pins | 12Pins |
|---|---|---|---|---|---|---|---|
| Rated Voltage | 500V | 250V | |||||
| Rated Current | 20A | 10A | 5A | ||||
| Insulation voltage | 2.5KV | 1.5KV | |||||
| IP CODE | IP68 | ||||||
| Cable Jacket OD | Standard Power: ⌀8-12mm Standard Signal: ⌀5-6.5mm Other: ⌀5-9mm | ||||||
| Assembly cable diameter | 2.4-4mm²/14-12AWG | 1-1.5mm²/18-16AWG | 0.34-0.75mm²/22-20AWG | ||||
| Ambient temperature | -40℃~+80℃ | ||||||
Advantages:
- Material & Performance:
The housing is made of high-performance PBT engineering plastic, ensuring stable electrical properties, excellent heat resistance, and corrosion resistance. The gold-plated conductive components guarantee superior conductivity and meet temperature rise requirements even in high-temperature environments. - Secure Locking Mechanism:
Features a push-to-lock snap-fit design for secure mating and smooth insertion/removal. - Waterproof Design:
Standard IP67 rating (IP68 optional) provides precise waterproof protection. - Certifications & Compliance:
Complies with TUV, ISO, CE, and RoHS certifications, meeting global market requirements.
Application industries
- Automation Equipment
- LED Lighting
- Security Equipment
- Telecommunication Equipment
- New Energy
- Electronic Devies
LP20 Series 20A IP68 3-Pin Waterproof In-Line Connector Drawing
FAQ
1. Q: What does the "IP68" rating mean for this in-line cable connector, and how does it perform in wet environments?
A: The IP68 rating indicates complete protection against dust ingress (6) and the ability to withstand continuous submersion in water beyond 1 meter depth, under conditions specified by the manufacturer (8). This makes the connector ideal for demanding environments such as outdoor installations, marine applications, or any scenario where exposure to heavy rain, temporary flooding, or high-pressure washing is expected.
2. Q: Why does this connector use a hybrid Metal-Nylon design, and what are the benefits?
A: The Metal-Nylon hybrid housing combines the superior mechanical strength and electromagnetic shielding properties of metal with the corrosion resistance, electrical insulation, and lightweight characteristics of nylon. This design ensures durability in rugged conditions while providing reliable protection against impacts, vibrations, and environmental corrosion.
3. Q: Is the solder termination type suitable for field repairs or applications requiring frequent disconnections?
A: Solder terminations provide a permanent, highly reliable, and vibration-resistant connection. They are ideal for applications where long-term stability is critical. However, for field repairs or situations requiring frequent mating and unmating, we recommend considering our LP20 Series models with screw-terminals or quick-disconnect options, which offer easier maintenance and reconfiguration.
