Waterproof Junction Box IP68 - 1-in-3-Out Cable Gland Through-Type for Data Power Lines
Connection Type: Screw-Type
Type: 1-in-3-out
Material: Plastic
Applicable Wire Gauge: 0.5mm²-6mm²
Outer Diameter (OD): 3*M20:5-9mm 9-12mm,2*M25:5-9mm 9-12mm 10-14mm
P/N : CB-2068S-4TA
| Parameter | Specification |
|---|---|
| Product Name | 2T/3T/4TA/4TB/5T/6T Junction Box |
| Wiring Range | 0.5 - 6 mm² |
| Rated Current | 4000MA |
| Operating Voltage | 0.45KV |
| Ingress Protection (IP) Rating | IP68 |
| Ambient Temperature | -40℃ ~ +105℃ |
| Cable Diameter (OD) | 5 - 9 mm, 9 - 12 mm,10-14mm |
| Connector Size | 2*M25/1*M20,2*M25/2*M20,2*M25/3*M20,2*M25/4*M20,2*M25 |
-
1. Ultimate IP68 Protection
Guarantees complete defense against water, dust, and harsh elements for maximum reliability in demanding environments.
-
2. Efficient 1-in-3-Out Distribution
Simplifies installation by organizing multiple connections in one compact unit, saving space and time.
-
3. Universal Data & Power Compatibility
Designed to handle both electrical power cables and data/communication lines with equal reliability.
-
4. Robust Through-Type Design
Provides secure cable entry sealing that maintains protection even under continuous vibration or pressure.
-
Additional optional benefits:
-
Easy Maintenance Access
Features a user-friendly design that allows for simple inspection and rewiring without compromising the seal.
-
Corrosion-Resistant Construction
Built with durable materials to withstand outdoor, industrial, and marine applications long-term.
-
A: The IP68 rating certifies that the box is completely dust-tight (6) and can be continuously submerged in water beyond 1 meter depth (8), ensuring maximum protection.
A: Yes, its universal design and gland system are engineered to safely and securely manage both standard electrical power lines and sensitive data/communication cables.
A: The through-type (or feed-through) design allows cables to pass straight through the enclosure, simplifying wiring for in-line applications and creating a neat, organized setup.
