4×2 HOWO 371HP 420HP Trailer Head for Shipping Cost and Estimated Delivery Time

Price Negotiable

Price: Negotiable

MOQ: Negotiable

Delivery Time: Peak Season Lead Time: within 15 workdays, Off Season Lead Time: within 15 workdays

Product Description

HOWO
Driving Type	Left Hand Driving
Cabin	HW76
Engine	Make: SINOTRUK wd615.47
Transmission	HW19710, 12F & 2R, with PTO
Steering	ZF power steering, model ZF8118, hydraulic steering with power assitance
Front Axle	HF9 SSteering with doubleT-cross section beam
Rear Axle	AC16, 2×16000 KGSPressed axle housing, central single reduction with hub reduction and with differential locks between wheels and axles.Ratio:5.73
Propeller Shaft	Double universal joint propeller shaft with gear-shaped coupling flange
Chassis	Frame: U-profile parallel ladder frame with section of 300x80x8mm, and reinforced sub-frame all cold riveted cross members Front suspension:10 semi-elliptic leaf springs, hydraulic telescopic double-action shock absorbers and stabilizer Rear suspension:12 leaf semi-elliptic springs, bogie spring and stabilizer
Brake	Service brake: dual circuit compressed air brakeParking brake (emergency brake): spring energy, compressed air operating on front shaft and rear wheelsAuxiliary brake: engine exhaust brake
Electrics	Operating voltage: 24 V, negative grounded Starter: 24 V, 5.4 Kw Alternator: 3-phase, 28 V, 1500 W Batteries: 2 x 12 V, 165 Ah Cigar-lighter, horn, headlamps, fog lights, brake lights, indicators and reverse light
Tires	12.00r20, radial tires with one spare tire.
Fuel Tank	400 L
Cargo Body	560023001500 mm, Floor 8 mm and side 6 mm,
Overall Dimension	820025503500 mm
