16GG Fully Jacquard Flat Knitting Machine Double System 52inch for High Production
Price:
$7,000.00/sets 1-9 sets
MOQ:
Negotiable
Delivery Time:
Negotiable
Brand:
OPEK
Product Description
Product descript
52 inch Economy Double system computerized flat knitting machine
This system is automatic computerized flat knitting machine
It adopts digital technology to realize the knitting functions transfer tuck,eyelet stitch,jacquard,apparent shape, hidden shape and other regular pattern knitting functions.
It can knit basic stitch like plain stitch,rib fabric,links and interlock stitch,etc.
Irregular multi-color jacquard,twisted flower weft organization,cord weave,racked stitch,cable,intarsia,etc.
It is suitable to use synthetic,wool,acrylic,mixed fiber,yarn material etc to knit ready-made sweater,collar ,vamp
,hat,gloves,scarf and accessories of cloth. So as to achieve multi-functional all-in-one machine
Workshop assembly line after layer upon layer of strict testing to ensure the stable and efficient work of the machine
LCD Touch screen
Humanized design control interface large memory capacity, can store about 1000 patterns, for tens of thousands of lines of complex
patterns can also be read quickly without waiting. Stable performance make the operation more convenient, easy to learn
ndunderstand.
patterns can also be read quickly without waiting. Stable performance make the operation more convenient, easy to learn
ndunderstand.
Positive feed yarn device
Positive yarn feed device could reduce resistance while yarn is moving , suit for fabrice with lace of elasticity and brittle
fabric to make the fabric even and improve knitting efficiency.
fabric to make the fabric even and improve knitting efficiency.
Motorized inversion bar & Tight handing head
The carriage inversion bar driven by motor ,carriage return is more accurate Tight is controlled by the motor ,to achieve
different degrees of tight tuck,ranging from 0 to 80 .
different degrees of tight tuck,ranging from 0 to 80 .
Ultra-small Carriage
Further optimize the size of the machine carriage ,reduce the carriage return distance and improve the efficiency .
16 yarn carriages
The 16 yarns can be used by any weaving system and can be switched at any position. According to different knitting speed the
control program can automatically adjust the position of the yarn nozzle.
control program can automatically adjust the position of the yarn nozzle.
Plus wide transmission belt
Specifical design double row synchronizing transmission belt let the machine with more stable running performance .
Mainly specification
Gauge : | 3G,3.5G,5G,7G,8G,9G,10G,12G,14G,16G,3-5-7G multi-gauge | ||||
Knitting width : | 52 inches (60, 72, 80 inches Customizable) | ||||
knitting function: | Jacquard,Transfer,Miss,Intarsia,Pointelle,Cable,Hide And Other Regular Pattern Knitting Fuctions.(Noted:Tuck can't be knitted with other knitting action in same line) | ||||
Knitting speed: | 1.4m/Second(Max), 32 section adjustable | ||||
Knitting system: | Single carriage with Double System | ||||
Stitch density: | Controlled by 32 section electricity, density adjustment driven by stepping motor, range: 0-650 | ||||
Needle Bed Racking: | AC Servo Motor drive, the maximum racking within 2 inches | ||||
Needle Selection System: | 8 section electronic needle actuator | ||||
Yarn Feeder: | 2 pcs Proactive Yarn Feeders | ||||
Stitch system: | 2*8 yarn carriers are arranged on the left and right sides of the 4 double side guide rails. | ||||
Yarn Carriers: | Advanced encoder reading pin.8-stage selecting needle setup composed of special electromagnet is regarded as efficient full width jacquard needle selector. | ||||
Transmission system: | Belt drive, High precision AC servo motor control. | ||||
Data input: | Input and output patterns via USB, PC and Internet | ||||
Protection system: | Automatic stopping device if yarn broken, yarn knot, batching, striking, completion, overload, designated starting and stopping, program error | ||||
Safety device: | The whole machine cover to reduce noise and dust, the protecting cover is equipped with stopping sensor, emergency stopping and power off device | ||||
Network | Has network interface,enable remote-monitoring via network,and connecting with ERP system. | ||||
Power Supply: | Voltage: AC 220V, Frequency: 50HZ/60HZ, Power:1KW | ||||
Volume and weight | 2450*900*1800mm 700kgs | ||||
Knitting samples
Company Show
OPEK workshop
Packing & Delivery
Successful case
Certifications and Honor
