Touch Screen Paperboard Bursting Strength Tester ISO 2759 GB/T 1539 QB/T 1057
Price:
Negotiation
MOQ:
1SET
Delivery Time:
15 Days
Brand:
HBYIQI
Product Description
Transportation Vibration Tester Paperboard Bursting Strength Machine 250～6000kPa
Brand: HBYIQI
Equipment Name: Paperboard Bursting Strength Tester (Touch Screen Model)
Equipment Model: HB-G06-B
Equipment Purpose:
Suitable for determining the bursting strength of paperboard, corrugated board and other sheet materials.
Adopted Standards:
ISO 2759: Determination of Bursting Strength of Paperboard;
GB/T 1539: Determination of Bursting Strength of Paperboard;
QB/T 1057: Paper and Board Bursting Tester.
Technical Parameters:
| Specification Model | HB-G06-B |
| Induction Mode | Pressure transducer |
| Stored Results | With printing function, can print 10 groups of data and automatically calculate the average value |
| Display Mode | High-definition touch screen control display, digital A/D conversion rate 100 times/S, high test accuracy |
| Force Unit | kgf/cm², Lb/in², Kpa (with unit switching function) |
| Measurement Range | 250～6000kPa, 0-100 kg/cm² |
| Resolution | 1kPa |
| Measurement Accuracy | Indication error:Better than ±1%FS |
| Indication variability:Better than ±1% | |
| Oil Pressure Speed | High-pressure type 170±10ml/min |
| Rubber Membrane Resistance | 10mm protrusion, 170kPa～220kPa 18mm protrusion, 250kPa～350kPa |
| Clamping Ring Material | Stainless steel |
| Clamping Force | >690Kpa (adjustable) |
| Inner Diameter of Upper Clamping Ring Hole (mm) | φ(31.5±0.05)mm |
| Inner Diameter of Lower Clamping Ring Hole (mm) | φ(31.5±0.05)mm |
| Diameter of Upper Clamping Disk (mm) | 95mm |
| Diameter of Lower Clamping Disk (mm) | 135mm |
| Hydraulic Oil | Silicone oil |
| Volume (mm) | 430530520mm |
| Weight | Approximately 60KG |
| Power Supply | 1∮, AC220V |
| Standard Configuration | 5 rubber membranes, 1 wrench, 10 calibration sheets, 1 bottle of silicone oil |
Product Advantages:
- After the paperboard is crushed, it automatically stops and returns to the initial position;
- Fully automatic one-key operation;
- Can store 50 groups of data at the same time;
- Equipped with a micro printer, which can print test results;
- Equipped with an emergency stop button to improve operational safety;
- Equipped with an air pressure gauge to monitor pressure at any time;
- High-definition LCD display.
- It changes the traditional method of using glycerin + water and adopts silicone oil instead, which makes the machine less likely to rust and prolongs the service life of the machine.
For more information, please contact the salesperson.
